					OAL
T890HT ELN-R13
90° Endmills Carrying T890 LN.T 1306... Tangentially Clamped Inserts with 8 Cutting Edges				DC APMX LU LH			DCONMS
Designation	DC	APMX	CICT(1)	DCONMS	Shank(2)	LU	LH	OAL	WT(3)
T890HT ELN D32-3-C32-13	32.00	9.50	3	32.00	C	37.4	40.0	130.00	0.68
T890HT ELN D32-3-C32-13B	32.00	9.50	3	32.00	C	47.4	50.0	250.00	1.43
T890HT ELN D32-3-W32-13	32.00	9.50	3	32.00	W	37.4	40.0	110.00	0.56
T890HT ELN D40-4-C32-13	40.00	9.50	4	32.00	C	-	44.0	130.00	0.12
T890HT ELN D40-4-W32-13	40.00	9.50	4	32.00	W	-	40.0	115.00	0.69

(1) Number of inserts (2) C-Cylindrical, W-Weldon (3) Item weight

				DHUB DCOMN	S
T890HT FLN-R13 90° Face Mills Carrying
T890 LN.T 1306... Tangentially Clamped Inserts with 8 Cutting Edges				DC	A	PMX OA	L
Designation	DC	APMX	CICT(1)	DCONMS	DHUB		OAL	Arbor	kg
T890HT FLN D040-03-16-R13	40.00	9.50	3	16.00	38.00		40.00	A	0.22
T890HT FLN D040-04-16-R13	40.00	9.50	4	16.00	38.00		40.00	A	0.21
T890HT FLN D040-05-16-R13	40.00	9.50	5	16.00	38.00		40.00	A	0.21
T890HT FLN D050-04-22-R13	50.00	9.50	4	22.00	48.00		40.00	A	0.33
T890HT FLN D050-05-22-R13	50.00	9.50	5	22.00	48.00		40.00	A	0.33
T890HT FLN D050-06-22-R13	50.00	9.50	6	22.00	48.00		40.00	A	0.35
T890HT FLN D063-06-22-R13	63.00	9.50	6	22.00	48.00		40.00	A	0.48
T890HT FLN D063-07-22-R13	63.00	9.50	7	22.00	48.00		40.00	A	0.48
T890HT FLN D063-08-22-R13	63.00	9.50	8	22.00	48.00		40.00	A	0.50
T890HT FLN D080-06-27-R13	80.00	9.50	6	27.00	60.00		50.00	B	0.88
T890HT FLN D080-07-27-R13	80.00	9.50	7	27.00	60.00		50.00	B	0.89
T890HT FLN D080-09-27-R13	80.00	9.50	9	27.00	60.00		50.00	B	0.91
T890HT FLN D100-08-32-R13	100.00	9.50	8	32.00	78.00		50.00	B	1.49
T890HT FLN D100-12-32-R13	100.00	9.50	12	32.00	78.00		50.00	B	1.62
T890HT FLN D125-09-40-R13	125.00	9.50	9	40.00	92.00		63.00	B	2.83
T890HT FLN D125-15-40-R13	125.00	9.50	15	40.00	92.00		63.00	B	2.93

(1) Number of inserts
