SPINJET COOLENT DRIVEN HSM SPINDLES ER32 ER11 DCONXWS G2.5 TJS HPC ER BD BD_2 BD_3 70 60,000 RPM BD_4 Bar Max U<1.0 gmm High-Pressure Coolant Driven LB HSM Spindle with ER32 Shank LB_2 for Small Diameter Cutting Tools LB_3 LB_4 LBX LPR For ER-SPR collets use "AA" type only OAL kg Designation BD BD_2 BD_3 BD_4 LB LB_2 LB_3 LB_4 LBX LPR OAL SS DCONXWS(1) RPMN(2) RPMX(3) CDI(4) TJS HPC ER32 16.00 71.25 80.00 81.00 17.31 24.89 37.81 79.41 103.00 114.21 143.00 ER32 7.00 25000 45000 0 1.70 • Coolant pressure 15-70 bar and flow rate 10-22 l/min • RPM range 20,000-45,000 RPM • The spindle provides only external strong coolant jet around the tool • Battery not supplied • For user guide, see pages 701-703 (1) Maximum diameter (2) Minimum RPM (3) Maximum RPM (4) 1 - Hole for data chip, 0 - Without hole for data chip Spare Parts Designation TJS HPC ER TJS TSD DISPLAY* NUT ER11 GHS WRENCH ER11 SMS HW 2.0 TJS SHAFT LOCK KEY * Optional, should be ordered separately SS BD_4 ER11 DCONXWS G2.5 TJS HPC BT BD BD_2 BD_3 70 Bar Max 60,000 RPM U<1.0 gmm High-Pressure Coolant Driven HSM Spindle with BT Shank for LB_2 LB Small Diameter Cutting Tools LB_3 LB_4 LBX LPR For ER-SPR collets use "AA" type only OAL kg Designation BD BD_2 BD_3 BD_4 LB LB_2 LB_3 LB_4 LBX SS LF LPR DCONXWS(1) OAL RPMN(2) RPMX(3) CDI(4) TJS HPC BT40 16.00 71.25 80.00 81.00 17.00 24.58 37.50 79.10 90.30 BT40 100.00 117.00 7.00 183.00 25000 45000 0 1.90 • Coolant pressure 15-70 bar and flow rate 10-22 l/min • RPM range 20,000-45,000 RPM • The spindle provides only external strong coolant jet around the tool • Battery not supplied • For user guide, see pages 701-703 (1) Maximum diameter (2) Minimum RPM (3) Maximum RPM (4) 1 - Hole for data chip, 0 - Without hole for data chip Spare Parts Designation TJS HPC BT TJS TSD DISPLAY* NUT ER11 GHS WRENCH ER11 SMS HW 2.0 TJS SHAFT LOCK KEY * Optional, should be ordered separately BD_4 ER11 G2.5 DCONXWS TJS HPC HSK DCONMS BD_2 BD_3 70 Bar Max 60,000 RPM U<1.0 gmm BD High-Pressure Coolant Driven HSM Spindle with HSK Shank LB LB_3 LB_2 for Small Diameter Cutting Tools LB_4 LBX LPR OAL For ER-SPR collets use "AA" type only kg Designation BD BD_2 BD_3 BD_4 LB LB_2 LB_3 LB_4 LBX DCONMS DCONXWS(1) LF LPR OAL RPMN(2) RPMX(3) CDI(4) TJS HPC HSK A63 16.00 71.30 80.00 81.00 17.30 24.90 37.80 79.40 112.00 63.00 7.00 121.00 138.00 170.00 25000 45000 0 2.00 • Coolant pressure 15-70 bar and flow rate 10-22 l/min • RPM range 20,000-45,000 RPM • The spindle provides only external strong coolant jet around the tool • Battery not supplied • For user guide, see pages 701-703 (1) Maximum diameter (2) Minimum RPM (3) Maximum RPM (4) 1 - Hole for data chip, 0 - Without hole for data chip Spare Parts Designation TJS HPC HSK TJS TSD DISPLAY* NUT ER11 GHS WRENCH ER11 SMS HW 2.0 TJS SHAFT LOCK KEY * Optional, should be ordered separately 706 ISCAR
