MILLING INSERTS OEMT/OEKT 060405 Octagonal Milling Inserts IC for General Use 45° APMX BS RE S Recommended Dimensions Tough 1 Hard Machining Data ap fz IC5400 IC5100 IC330 IC830 IC808 IC810 IC28 Designation IC APMX BS RE S (mm) (mm/t) OEMT 060405AER-76 14.27 2.50 1.60 0.50 4.74 • • • • • • • 1.00-2.45 0.15-0.25 • For cutting speed recommendations, see pages 542-547 For tools, see pages: HOE-R06 (218) • HOF-R06 (218) OEMW-AETN Octagonal Flat Rake IC Inserts for Cast Iron APMX BS 45° S RE Dimensions Tough 1 Hard Recommended Machining Data ap fz IC928 IC808 Designation IC APMX BS RE S (mm) (mm/t) OEMW 060405-AETN 14.27 2.45 1.05 0.50 4.74 • • 1.00-2.45 0.15-0.30 • For cutting speed recommendations, see pages 542-547 For tools, see pages: HOE-R06 (218) • HOF-R06 (218) RE Rd° OFMT 07 Octagonal Milling Inserts for General Use IC APMX BS S Economical solution Recommended Dimensions Tough 1 Hard Machining Data ap fz IC330 IC328 IC830 IC928 IC910 IC28 Designation IC APMX BS RE S (mm) (mm/t) OFMT 07T3-AER-76 17.80 3.40 1.75 0.60 4.55 • • • 1.00-3.00 0.15-0.25 OFMT 07T3-AEN 18.07 3.90 1.60 0.60 4.54 • • 1.00-3.00 0.15-0.25 OFMT 07T3-AETN (1) 18.07 3.90 1.75 1.00 4.54 • • 1.00-3.00 0.20-0.35 • For cutting speed recommendations, see pages 542-547 (1) Reinforced cutting edge For tools, see pages: HOF-R07 (219) OFMT 07...-AER-76 OFMT 07T3-AEN/AETN For general use For general use Reinforced cutting edge 506 ISCAR
