R.250

.510 .510 .512

.510 R.060 .200 .510 R.060 .200 .512 .200

SDES130563R-001 SDMS130508R-PH SDMS130515R-PH

R.250

.512 .512 .512

.512 .200 .512 R.031 .200 .512 R.060 .200

ZDES130515R ZDES130515R-001 ZDMS130515R-PH

.510 .510 .512

.510 R.060 .200 .510 R.060 .200 .512 R.060 .200

Part Number Application Station ades IN2505 IN2530 IN4005 IN4015 IN4030 IN4035

SDES130515N	Flat Top - Landed Edge - 0.060“ R	Side
SDES130515N-001	Flat Top - Keen Edge - 0.060“ R	Side
SDES130563R	Flat Top - Landed Edge - 0.250“ R	End
SDES130563R-001	Flat Top - Keen Edge - 0.250“ R	End
SDMS130508R-PH	Positive Geometry - 0.031“ R	Side
SDMS130515R-PH	Positive Geometry - 0.060“ R	Side
ZDES130515R	Flat Top - Splitters - Landed Edge - 0.060“ R	Side
ZDES130515R-001	Flat Top - Splitters - Keen Edge - 0.060“ R	Side
ZDMS130515R-PH	Positive - Splitters - 0.060“ R	Side

HARDWARE

	Screw	Driver Handle	Screw Driver Blade	Driver Bit (Optional)	Torque Driver Handle (Optional)
SM40-100-R0		DS-A00T	DS-T156B	DS-T15B1		DT-35-02
