SERIES 5G_M 5M6P-30R01 5G6M-30R01 19MM INSERTED CUTTERS, HIGH FEED 13mm Facemill 19mm Facemill Shoulder Ramping Pocket Contour Coolant D2 D2 K K H H Positive D5 Positive D5 Axial Rake Axial Rake D1 D1 SDES1906MDR, SDMS1906MDR-PH, SDES190620N, SDES1906MPR, SDES1906MPR-001 SDES190620N-001, SDMS190620R-PH D2 D1 D5 15M1P-1505386R01Max. D1 D5 Max. Cutter # of K H H Nom. Bore Coolant Program Effective 13mm EndmillRamp Program Effective Ramp Number Inserts Keyway Height Height Dia. Dia. OD Dia. Dia. Angle OD Dia. Dia. Angle 5G5M-30R01 3.000 6 1.00 0.375 yes 3.000 1.766 2.000L3 1.6 2.961 1.903 1.981 1.2 5G6M-30R01 3.000 5 1.00 0.375 no 3.000 1.755 L2 2.000 1.6 2.961 1.894 1.981 1.2 5G5M-40R01 4.000 8 1.50 0.625 yes 4.000 D1 D5 2.769 2.500 1.0 3.961 D2 2.906 2.481 0.8 5G6M-40R01 4.000 6 1.50 0.625 no 4.000 2.755 2.500 1.0 3.961 2.894 2.481 0.8 5G5M-50R01 5.000 9 1.50 0.625 yes 5.000 3.759 2.500 1.7 4.961 3.897 2.481 0.6 5G6M-50R01 5.000 7 1.50 0.625 no 5.000 3.755 2.500 L2 0.7 4.961 3.894 2.481 0.6 5G5M-60R01 6.000 10 1.50 0.625 no 6.000 4.757 2.500 0.6 T1 5.961 4.896 2.481 0.4 5G6M-60R01 6.000 8 1.50 0.625 no 6.000 D14.755 D5 2.500 0.6 5.961 4.894 2.481 0.4 Operating Guidelines on page 96. FACEMILL HARDWAREL2 T1 Cutter D1 D5 Number Screw Driver Driver Bit Retention Bolt Coolant Thru Retention Bolt 5G5M-30R01 SM60-135-R0 DS-T25T n/a SD-08-47 SD08-C9 5G6M-30R01 SM60-135-R0 DS-T25T n/a SD-08-47 - 5G5M-40R01 SM60-135-R0 DS-T25T n/a SD-12-82 SD12-99 5G6M-40R01 SM60-135-R0 DS-T25T n/a SD-12-82 - 5G5M-50R01 SM60-135-R0 DS-T25T n/a SD-12-82 SD12-99 5G6M-50R01 SM60-135-R0 DS-T25T n/a SD-12-82 - 5G5M-60R01 SM60-135-R0 DS-T25T n/a SD-12-82 - 5G6M-60R01 SM60-135-R0 DS-T25T n/a SD-12-82 - 5M5P-20R01 SM40-100-R0 DS-A00T BLD T15/S7 SD-06-48 SD06-A6 5M6P-20R01 SM40-100-R0 DS-A00T BLD T15/S7 SD-06-48 SD06-A6 5M6P-25R01 SM40-100-R0 DS-A00T BLD T15/S7 SD-06-48 SD06-A6 5M5P-25R01 SM40-100-R0 DS-A00T BLD T15/S7 SD-06-48 SD06-A6 5M5P-30R01 SM40-100-R0 DS-A00T BLD T15/S7 SD-08-47 SD08-C9 5M6P-30R01 SM40-100-R0 DS-A00T BLD T15/S7 SD-08-47 SD08-C9 5M5P-30R02 SM40-100-R0 DS-A00T BLD T15/S7 SD-10-47 SD10-99 5M6P-30R02 SM40-100-R0 DS-A00T BLD T15/S7 SD-10-47 SD10-99 5M5P-40R01 SM40-100-R0 DS-A00T BLD T15/S7 SD-12-82 SD12-99 5M6P-40R01 SM40-100-R0 DS-A00T BLD T15/S7 SD-12-82 SD12-99 5M5P-50R01 SM40-100-R0 DS-A00T BLD T15/S7 SD-12-82 SD12-99 5M6P-50R01 SM40-100-R0 DS-A00T BLD T15/S7 SD-12-82 SD12-99 47
