TDA FULL RADIUS PRECISION INSERTS FOR ALUMINUM MACHINING ID Undercutting OD Turning OD Profiling R W B A° L H Insert W W R L H A Grade Designation Seat ±.02 ±.0008 ±.002 K10 (inch) (inch) (degree) Size (mm) (inch) (inch) TDA6.00-3.00 6 6.00 0.236 0.118 0.98 0.205 7 TDA8.00-4.00 8 8.00 0.315 0.157 1.18 0.252 10 Use holders TTER/L, TGIUR/L, TTER/L-15A, see pages 1317, 1328 - 1330. = P = M = K = N = S =H TSA PCD TIPPED INSERTS FOR ALUMINUM WHEEL MACHINING ID Undercutting OD Turning OD Profiling R W B A° L H Insert W W R L H A Grade Designation Seat ±.02 ±.0008 ±.002 KP300 (inch) (inch) (degree) Size (mm) (inch) (inch) TSA6.00-3.00 6 6.00 0.236 0.118 0.98 0.205 7 TSA8.00-4.00 8 8.00 0.315 0.157 1.18 0.252 10 Use holders TTER/L, TGIUR/L, TTER/L-15A, see pages 1317, 1328 - 1330. = P = M = K = N = S =H 1291 1291
