GBP 57 ​ Plastic pipe cutter BiX® Pipe cutter of sturdy reinforced plastic, blade block of die-cast zinc. Particularly easy to use, for cutting off pipes without burrs or swarf. Safe, correct cutting of drip sleeves during final installation – virtually flush with the wall (approx. 2 – 3 mm from the wall). Rotating blade block for cutting plastic pipes (central blade) and cutting drip sleeves and sealing sleeves (outer blade). Locking mechanism for safe transportation. Application: Cuts objects including high-temperature waste water pipes, empty electrical conduits and non-reinforced plastic pipes with a wall thickness of up to 2.4 mm in next to no time. for ⌀ to mm 50 81 9780 81 9780 86A Plastic pipe cutter BiX® with 3 blades eShop for pipe outer ⌀ mm 20 – 50 ​ Pipe cutter DP50 for HT pipes, 2 in 1 Tool body of glass-fibre-reinforced plastic. Exchangeable blade of high-quality ball bearing steel, can be changed with no tools required. Optimum pipe guidance and easy cutting thanks to self-adjusting rollers with plain bearings. The spring-mounted cutting blade means there is no need for tedious adjustment whilst Pressing on the blue lever cutting. allows the tube to be Advantage: One tool, two functions, three diameters. Easily and neatly cut and chamfer common inserted and the cutter plastic wastewater pipes in a single step. Smooth cut: No adjustment, no deburring and blade to be positioned precisely. a reduced risk of clogging or damage to the seal. Application: Cuts HT pipes and many other plastic pipes with ⌀ 32, 40 or 50 mm and a wall thickness of up to 2.4 mm. Easy to position thanks to clear view of the cut-off point. Final cuts or fine cuts are possible from a section length of approx. 10 mm. Spare part: For replacement blade see No. 818191 size 1 and replacement quick-change pivot pin No. 818192 size 1. Use the slider to set the appropriate tube size. Type 1 81 8190 86A Pipe cutter DP50 for HT pipes eShop for pipe outer ⌀ mm 32; 40; 50 Length mm 202 Weight g 294 81 8190 ​ Pipe cutter for composite and plastic pipes For cutting composite and plastic pipes up to ⌀ 26 mm. With ergonomic multi-component grips and locking mechanism for safe transport. Material: Special quality chrome-vanadium electro-steel, oil-quenched. Advantage: ■ Up to 60% less force required: freely rotating cutting wheel allows for low-friction rotation of the pipe when cutting. 81 ■ Optimum cutting result: the rotational movement allows effortless penetration of the cutting wheel with minimal deformation of the tube. ■ Wide plastic moulded pads allow perfectly rectangular sections. ■ Allows very short correction cuts. ■ Separates aluminum composite and plastic pipes more easily than conventional shears with fixed cutter tool. Application: Also for composite pipes with increased aluminum layer thickness (such as Geberit Mepla). Spare part: See No. 819461 size 1 for spare cutting wheel. for pipe outer ⌀ up to mm 26 81 9460 81 9460 86A Pipe cutter for composite and plastic pipes eShop Length mm 210 Weight g 391 877
