Ручные и измерительные инструменты Hoffmann Group 2026 - страница 853

GBP 57 Carbide DIN ISO 8039 5468 ​Carbide masonry drill Hammer drilling in concrete and tiles. Drill tipped with hard and tough carbide inserts and brazed at high temperature. Asymmetrical flute profile for good transport of drill dust. Hammer and rotary bits with strong carbide cutter tip. Application: Primarily for drilling fastening holes with hammer drills in concrete, masonry, natural and synthetic stone. Also for rotary drilling in hard and soft wood, plastics, acrylic and ceramic. 78 6070_8 Also suitable for drilling hardened steel due to corrected cutting edge. Size 14 – with reduced shank. ⌀ mm 3 4 5 6 7 8 9 10 12 14 78 6070 Carbide masonry drill eShop eShop eShop eShop eShop eShop eShop eShop eShop eShop 71C Working length mm 30 40 50 60 60 80 80 80 85 85 Overall length mm 60 75 85 100 100 120 120 120 150 150 Shank ⌀ mm 3 4 5 6 7 8 9 10 12 10 78 6001_6 Size 13; 14 – With reduced shank. Size 16–20 – With stepped shank with 3 drive flats. 78 6001_20 ⌀ mm 3 3,5 4 5 5,5 6 6,5 7 8 78 6001 76G Carbide masonry drill eShop eShop eShop eShop eShop eShop eShop eShop eShop Working length mm 30 30 35 45 60 60 60 55 60 Overall length mm 60 60 70 85 100 100 100 100 110 Shank ⌀ mm 3 3.5 4 5 5.5 6 6.5 7 8 ⌀ mm 9 10 11 12 13 14 16 18 20 78 6001 76G Carbide masonry drill eShop eShop eShop eShop eShop eShop eShop eShop eShop Working length mm 60 60 90 90 85 85 85 95 95 Overall length mm 110 110 150 150 150 150 150 160 160 Shank ⌀ mm 9 10 11 12 10 10 12.75 12.75 12.75 Carbide masonry drill set ​ Number of drills 5 7 78 78 6078 Carbide masonry drill set eShop eShop 71C Content: 1 pc. each size 4; 5; 6; 8; 10 1 pc. each size 3; 4; 5; 6; 7; 8; 10 78 6078_7 Drill No. 786070 Number of drills 5 7 78 6081 76G Carbide masonry drill set eShop eShop Content: 1 pc. each size 4; 5; 5.5; 6; 7; 8; 1 pc. each size 4; 5; 6; 8; 10 Drill No. 786001 10 78 6081_5 Carbide max. 200 min-1 Fine stoneware / tiles drilling set 2 pieces. A drill with a diamond-ground carbide tip with a patented centring tip for highly accurate start positioning and exact holes without break-outs. With 10 mm shank. A carbide drill for use in standard drill chucks. With 1/4 inch (E 6.3) hexagon shank. 78 7035 Application: For very hard stoneware tiles up to Mohs / scratch hardness class 9 and for glass and porcelain. Note: Not suitable for hammer drills. Maximum spindle speed 200 rpm. No cooling required. 78 7035 2​ . Drill a fastening hole into ​1. Drill a hole in the tile the masonry ⌀ mm 5 6 8 10 78 7035 76G Fine stoneware drill /tiles drill eShop eShop eShop eShop Overall length mm 105 115 120 120 853
