GBP 57 ​Large crimping tool for non-insulated tubular cable lugs and connectors Sturdy head with compound action and integral rotatable form wheels. Tubular handles with plastic grips. Cross-section assignment visible on the form wheels. 72 9905 – Form wheel adjustment by one-hand operation. Guarantees reliable cross-section assignment by synchronised form wheel adjustment. With ergonomic 2-component handle and slip protection on both sides. Size K06SYNCRO – Extendable lever arms. 72 9970 – With innovative i-crimping, suitable for multi-core compacted and fine stranded cables. I-crimping allows values far in excess of normal requirements to be achieved. Application: For non-insulated tubular cable lugs and connectors (standard design). _K06SYNCRO – Note: Not suitable for DIN compression cable lugs or for French CNF cable lugs. Optimum force matching by Crimping tools for DIN and French CNF cable lugs available on request. adjustable telescopic handle. Hexagonal compression 72 9905_K06SYNCRO Type K05SYNCRO K06SYNCRO 72 9905 Large crimping tool eShop eShop 76C for conductor cross-section mm2 6 – 50 6 – 120 Weight kg 1.2 2.6 overall length mm 390 600 – 750 n for i t a b le evecables Su ressed comp 72 9970_120 72 Type 50 120 72 9970 Large crimping tool eShop eShop 76C for conductor cross-section mm2 6 – 50 10 – 120 Weight kg 1.5 3.7 overall length mm 380 535 ​ Sleeve pliers (three-pin pliers) 72 9932 – Plastic pliers body with 3 interchangeable steel pins. Opening width can be adjusted using the locking screw. Flexible for right and left-handed use. Application: 72 9932 – Easy installation (spreading) of sleeves of any kind on cables and lines. ​ 72 9932 Type 3.3 3.7 72 9932 Sleeve pliers eShop eShop 76C for cable outer ⌀ mm 4 – 14 6 – 15 maximum sleeve length mm 26 37 overall length mm 132 Type 3.3 3.7 Set of spare pins 72 9934 eShop eShop 76C 6 pieces ​ 72 9934 802
