GBP 57 HSS 118° HSS twist drill bit 1/4 inch hexagon shank to DIN 3126 C 6.3. Advantage: Quick, uncomplicated changes between drill, countersink, and screw bits. Application: Ideal for repair and assembly work in mobile situations. General purpose use in metal, wood and plastic. Special rivet hole sizes 3.1 and 5.1 mm. 67 6302 Drill ⌀ mm 3 3,1 3,3 4 4,1 4,2 5 5,1 6 6,8 8 8,5 10 67 6302 63H HSS twist drill bit eShop eShop eShop eShop eShop eShop eShop eShop eShop eShop eShop eShop eShop Flute length mm 16 18 18 20 20 20 26 26 26 30 32 33 38 overall length mm 38 38 40 44 44 45 50 50 50 50 51 53 54 Shaft length mm 14 Twist drill bit set in a tool roll 67 6304 eShop 63H 19 pieces Content: No. 676302 1 pc. each size 3; 4; 4.2; 5; 6; 8 Jobber drill bits Bits for Phillips No. 675200 2 pcs. size 1/25; 3 pcs. size 2/25; 1 pc. size 3/25 Bits for internal TORX® No. 675340 1 pc. each size TX10; TX15; TX20; TX25; TX30; TX40 “Rapidaptor” adaptor 1 pc. similar to No. 675020 size 6.3K (without magnet) 67 6304 HSS Drill, tap, and countersink bit 1/4 inch hexagon shank to DIN 3126 C 6.3. Advantage: Application: Quick and uncomplicated changes between drill, countersink, and screw bits. Ideal for repair and assembly work in mobile situations. 67 67 6305 HSS stepped drill bit ​ 9 drill steps 2 mm increments, for use in materials up to 4 mm thickness. Drilling With edge breaker (sheet deburrer) at ⌀ 10 for 1 mm sheet metals. Thread cutting Drill step range mm 4-20 Deburring 67 6305 63H Stepped drill bit eShop overall length mm 67 Shaft length mm 20 Step height mm 4 Combination tap bit M ISO 2 6H 60° 60° ≤1×D Application: 1 tool for 3 operations: drill tapping hole − tap thread − deburr / countersink. For use in power drills with forward and reverse drive. for threads M3 M4 M5 M6 M8 M10 a 67 6306 67 6306 63H HSS combination tap bit eShop eShop eShop eShop eShop eShop overall length mm 36 39 41 41 51 59 Shaft length mm 12 Drill length a mm 5 6 7 8 11 15 Twist drill ⌀ mm 2.5 3.3 4.2 5 6.8 8.5 Pitch mm 0.5 0.7 0.8 1 1.25 1.5 NEW Number of pieces 7 67 6308 63H Combination tap bit set, 7 pieces eShop Content: No. 676306 1 pc. each size M3; M4; M5; M6; M8; M10 Combination tap bits „Rapidaptor” coupling shank 1 pc. similar to No. 675020 6.3K (without magnet) 67 6308_7 685
