GBP 57 ​Adaptor for bits (two-part system) Two-piece, i.e. shank and bit are separate. This means that in case of wear, only the relevant bit has to be replaced. GARANT and HOLEX ​ Adaptor with automatic quick-change coupling and magnet for C 6.3 and E 6.3 bits (the magnet holds the screw). ■ Holder for C 6.3 and E 6.3 bits. ■ The sleeve clicks into the open position. It locks automatically when a bit is inserted. ■ Even the smallest bits can be removed without problems, since the sleeve lifts the bit away from the magnet - quick change of bits, always one-handed. 67 5050_6,3 Hexagon 67 5050 67 5055 overall length Hexagon drive Machine drive 62F 61F shank 67 5055_6,3 ■ Holder for C 6.3 and E 6.3 bits. ■ The sleeve clicks into the open position. Shank with magnet / quick-change coupling 67 5050 67 5055 ​ ​ It locks automatically when a bit is inserted. mm mm ​ ​ 6,3 eShop eShop 50 60 D 6.3 (1/4 inch) E 6.3 (1/4 inch) WERA ​ 67 5000 – Adaptor to DIN 7427 B with snap ring. 67 5010 – Adaptor with magnet and snap ring for C 6.3 bits (the magnet holds the screw). 67 5020 – “Rapidaptor” adaptor with automatic quick-release adaptor and magnet for C 6.3 and E 6.3 bits (the magnet holds the screw). 67 5000_6,3 Size 6,3S – Of stainless steel “Stainless”, without magnet. Size 6,3R – The floating, free-running ring magnet sleeve reliably holds even long and heavy screws 67 (only for C 6.3 bits). 67 5030 – “Rapidaptor” BiTorsion adapter with automatic quick-change coupling and magnet for 67 5010_5,5 C 6.3 and E 6.3 bits. The integral precisely calculated torsion zone significantly reduces the load on the bits and therefore considerably increases their tool life. For use in combination with BiTorsion bits No. 675510 − 675550. Note: Rapidaptor free-running adapter available (No. 675035 size 6.3F). S/STL 67 5020_6.3S 67 5020 ■ Holder for C 6.3 and E 6.3 bits. ■ The sleeve clicks into the open position. It locks automatically when a bit is inserted. 67 5020_6,3 ■ Even the smallest bits can be removed without problems, since the sleeve lifts the bit away from the magnet. Quick change of bits, always one-handed. ■ Strong ring magnet reliably holds even long and heavy screws. 67 5030 Application example 67 5020_6.3R Hexagon 67 5000 67 5010 67 5020 67 5030 overall length Hexagon drive Machine drive 63H 63H 63H 63H shank Shank Shank Shank with magnet / with magnet / with snap ring quick-change coupling 67 5000 67 5020 ​ ​ snap ring 67 5010 67 5030 BiTorsion mm mm ​ ​ 5,5 – eShop – – 72 – D 6.3 (1/4 inch) A 5.5 (5.5 mm) 6,3 eShop – eShop eShop 57 75 D 6.3 (1/4 inch) E 6.3 (1/4 inch) 6,3S – – eShop – – 50 D 6.3 (1/4 inch) E 6.3 (1/4 inch) 6,3K – – eShop – – 52 D 6.3 (1/4 inch) E 6.3 (1/4 inch) 6,3R – – eShop – – 57 D 6.3 (1/4 inch) E 6.3 (1/4 inch) 671
