GBP 57 ​ High quality stereo microscopes M-series ■ Modular product range and thus optimum adaptation of the microscope to the application. ■ Common Main Objective (CMO) optical system: When the magnification is changed, sharpness remains constant. er ! e ord y ■ Ergonomic design. Pleasseparatel e ■ Version with ESD swingarm stand prevents damage from static discharges. h t i n g e s co p li g rve th Size M50 – Five-stage magnification changer: 6.3×; 10×; 16×; 25×; 40×. Obse f supply! Size M60 – Zoom positions: 7 configurable positions, for repetitive tasks. o Size M80 – Zoom positions: 8 configurable positions, for repetitive tasks. Base plate with anti-shock. Supplied with: Lens carrier, binocular inclined tube 45°, 2× eyepieces suitable for glasses wearers, 49 1753_M50 lens achromat 1.0×, stand, dust cover (antistatic). 49 1753 – Incident illumination incl. table insert black/white. 49 1754 – ESD swivel arm stand. Optional extras: LED illumination No. 491755 and transillumination No. 491777 size BLI. Note: Suitable camera systems available on request. 49 1753_M60 49 _M80 detail Type M50 M60 M80 Stereo microscope with incident illumination, 49 1753 (eShop) (eShop) (eShop) 49B without lighting Stereo microscope with ESD swivel arm stand, 49 1754 (eShop) (eShop) (eShop) _M80 49B without lighting Optics system Common Main Objective 54 Magnification (x-times) 6.3 – 40 6.3 – 40 7.5 – 60 Zoom 5:1 6:1 8:1 Field of vision ⌀ mm 5.75 – 36.5 5.75 – 36.5 3.8 – 30.7 106 106 Eyepiece 10×/23B Working distance mm 89.6 89.6 83.4 Base length (49 1753) mm 301 Base length (49 1754) mm 260 260 330 109 150 Base width (49 1753) mm 278 Base width (49 1754) mm 220 All stereo microscopes are supplied with a 45° binocular inclined Depth of focus mm 13.7 tube. Different product image for 491754. Lighting and accessories ​ For 58 mm lens. Size RL – Ring light for very bright and even illumination. Switchable segments using the integral control panel. Size NVI – Near Vertical Illumination, to look at recesses and holes, since the light falls almost vertically on the sample. Size SLI – 2-arm swan neck 300 mm long, 2 power LEDs and control unit on separate swan neck. Suitable for: Stereo microscope No. 491753, 491754 and S series No. 491785. LED display for active segments Size RL with Supplied with: 1 power supply unit incl. 2-metre mains cable. high-performance diffuser, Size RL – 1 high-performance diffuser. mounted Note: Size SLI – The adaptor set No. 491757 is required for installation. Type RL NVI SLI 49 1755 LED 3000 light (eShop) (eShop) (eShop) 49B Colour temperature K 5600 Working distance mm 65 – 150 60 – 150 60 – 150 49 1755_NVI 49 1755_ SLI With engagement in the case of crossed polarisation, to minimise gloss points. Suitable for: Ring lamp No. 494755 size RL. for type RL 49 1756 Polarisation set (eShop) 49B Suitable for: 49 1756 Size 1 – M series with incident illumination No. 491753. Size 2 – M series with swingarm stand No. 491754. Application: For fitting the swan neck LED No. 491755 size SLI. Type 1 2 49 1757_1 49 1757 Adapter set (eShop) (eShop) 49B 249
