GBP 57 ​Spur-gear block and tackle Each spur-gear block and tackle is factory overload-tested and supplied with a user manual and test certificate. All-steel construction. Needle bearings and ball bearings on all rotating parts. Automatic load pressure brake. 360° rotating forged hook. Note: Lifting capacity up to 20 tons, chain box and overload protection available on request. Safe working load t 0,25 0,5 1 2 08 6019 Spur-gear block and tackle Tralift™ eShop – – – 08Y 08 6019 08 6020 Spur-gear block and tackle VS III eShop eShop eShop (eShop) 08X Lifting force at nominal load (08 6019) daN 11 – – – Lifting force at nominal load (08 6020) daN 20 21 24 29 Standard lifting height m 3 Number of chains 1 1 1 2 Safe working load kg 250 500 1000 2000 Weight (08 6019) kg 3.2 – – – Weight (08 6020) kg 4.9 9 11.5 17.3 08 6020_1 ​ Spur-gear block and tackle Yalelift 360° Each spur-gear block and tackle is factory overload-tested and supplied with a user manual and test certificate. The 360° rotatable manual chain guide permits operation from all positions. Designed for heavy-duty use. Satisfies the latest European safety regulations. The user is no longer forced to work in the hazardous area of the load. Note: Lifting capacity up to 20 tons, chain box and overload protection available on request. Version with integrated power traverse, galvanised version and ATEX on request. Safe working load t 0,5 1 3 5 08 6025 Spur-gear block and tackle Yalelift 360° (eShop) (eShop) (eShop) (eShop) 08X Lifting force at nominal load daN 21 30 38 34 Standard lifting height m 3 Number of chains 1 1 1 2 Safe working load kg 500 1000 3000 5000 Weight kg 9 13 34 48 08 6025 ​ Electric chain hoists CPV/CPVF VEGO Electric chain hoist with lifting hook in robust and reliable design. The integral end-of-travel switch for the highest and lowest hook positions protects the clutch, motor, and housing and extends their working life. Drive group 1 Am, 50 % duty cycle at one speed, standard operating voltage (400 V / 50 Hz). Enhanced operating safety due to 42 V contactor controls, encapsulated control switches to Index of Protection IP65, motors to IP55. 08 6036 – With two speeds (precision lifting). Note: Versions with two speeds (precision lifting) and other lifting heights, power traverse, chain box and radio and 230 V power supply available on request. Type 0,25-8 0,5-4 0,5-8 1-4 1-8 2-4 08 6035 Electric chain hoist CPV VEGO – – (eShop) (eShop) (eShop) (eShop) 08Y 08 6036 Electric chain hoist CPVF VEGO (eShop) (eShop) – – – – 08Y Lifting speed m/min 8; 2 4; 1 8 4 8 4 Standard lifting height m 3 Number of chains 1 2 1 2 1 2 Safe working load kg 250 500 500 1000 1000 2000 Weight kg 18 21 26 28 58 63 08 6035_0,5-8 Battery-powered chain hoist Battery-powered electric chain hoist for mobile applications. No wiring required and ready for immediate use. Compact design, radio remote control with a range of up to 20 m. Robust design for use indoors and outdoors. Note: The suitable rechargeable battery can be found under No. 073805. NEW 08 Safe working load t 1 Battery-powered chain hoist 08 6037 (eShop) 08Y BatteryStar Lifting speed m/min 2.4 Standard lifting height m 6 ​ Number of chains 1 Safe working load kg 1000 Weight kg 20 1181
