GBP 57 ​Number and letter punch sets, DIN 7353 The parts are made of hard toughened steel and feature particularly precise machine engraving with depth limitation. They are manufactured to be precisely centred and have a calibrated, through-hardened shank. The annealed head ensures very safe working. 08 5401/5402/5446/5456 – Normal script, i.e. the punched character can be read directly on the component. 08 5401–5407 – High-performance precision punch, made of steel for maximum precision and very long tool life. 08 5403/5404 – Mirror script, i.e. the punched character appears laterally reversed on the component (for die making). 08 5406/5407 – Dotstress hand punch, punched, with a rounded nose, so that the material surface ilab le n s ava 08 5401 is exposed to lower stress when the punch is struck. ersio New v 08 5446/5456 – High quality, burnished surface. Application: For punching into materials with a strength up to 1200 N/mm2. Note: Other hand and machine punches of all types, such as punches with a company‘s logo etc., are available on request. 08 5402 Example of special punches 08 5446 08 5456 Engraved, Normal script Mirror script imprint Dotstress engraving, plan view imprint punched, plan view Character font and size (punched). Character height mm 1 2 3 4 5 6 8 10 12 Number punch set, 9 pieces 08 5401 08W eShop eShop eShop eShop eShop eShop eShop eShop eShop Normal script 0 − 9 Number punch set, 9 pieces 08 5403 08W – eShop eShop eShop eShop eShop – – – Mirror script 0 − 9 Number punch set, 9 pieces 08 5406 08W – – eShop eShop eShop eShop – – – Dotstress 0 − 9 Letter punch set, 27 pieces 08 5402 08W eShop eShop eShop eShop eShop eShop eShop eShop eShop Normal script A − Z, & Letter punch set, 27 pieces 08 5404 08W – eShop eShop eShop eShop eShop – – – Mirror script A − Z, & Letter punch set, 27 pieces 08 5407 08W – – eShop eShop eShop eShop – – – Dotstress A − Z, & Number punch set, 10 pieces 08 5446 02A – – eShop eShop eShop eShop – – – Normal script 0 − 9 Letter punch set, 27 pieces 08 5456 02A – – eShop eShop eShop eShop – – – Normal script A − Z, & overall length (08 5401, 08 5403, 08 5406, 08 5402, 08 5404, 08 5407) mm 63.5 63.5 63.5 70 70 70 89 89 89 overall length (08 5446, 08 5456) mm – – 61 62 62 68 – – – Shank thickness (08 5401, 08 5403, 08 5406, 08 5402, 08 5404, 08 5407) 6.35 6.35 6.35 9.5 9.5 9.5 12.7 14.3 14.3 Shank thickness (08 5446, 08 5456) – – 6.35 7.93 7.93 9.52 – – – ​ Punch holder Ergonomics and the high-grip surface of the holder permit a comfortable and secure grip. Suitable for all Hoffmann numeric punches and alphabetic punches. Type GRIP 08 5475 08W Punch holder eShop 08 ​ 08 5475 ​ Magnetic swarf catcher The integral permanent magnet attracts all magnetic swarf to its surface; overall length approx. 400 mm. ​ 08 4521 Length mm 400 08 4521 02A Magnetic swarf catcher eShop 1168
