44 K2
Cable drums
The cable drums meet the specifications set out in DGUV I 203‑006 (formerly BGI 608). 08 1106 – Sturdy cable drum with drum body made of sheet metal, double insulated front and back. 08 1113 – Plastic cable drum with all‑round rollover protection and practical folding handle.
Note: 08 1113 – A suitable holder for attachment to the GARANT roller cabinets and mobile workbenches can be found under 914935 1. 08 1106_25N‑4
| 25N-4 | 33N-4 | 40N-4 | 50B-4 | 50B-5 | ||
| 08 1106 | Cable drum steel core | eShop | – | eShop | eShop | – |
| 08 1113 | Professional plastic drum “Cube” | – | eShop | – | – | eShop |
Rated power unrolled W 3500 (16 A)
| Cable class | H07RN-F | H07RN-F | H07RN-F | H07BQ-F | H07BQ-F |
| Cable structure | 3G2.5 | 3G1.5 | 3G1.5 | 3G1.5 | 3G1.5 |
Rubber/neo- Rubber/neo- Rubber/neo- PUR (polyure- PUR (polyure- Material cable
| prene | prene | prene | thane) | thane) | ||
| Cable length | m | 25 | 33 | 40 | 50 | 50 |
| Number of sockets | 4 | 4 | 4 | 4 | 5 |
Diagnostic system present yes
Cable reel
Cable reel with guided automatic draw-in and roll-up, with multiple stop points per revolution. High‑impact enclosed plastic housing. Thermal overload cut-out, sturdy H07RN‑F neoprene cable with connection point. 08 1198/1192/1193 – Easy to mount on the wall or ceiling, with 180° pivoting range. 08 1194–1197 – Easy to mount on the wall or ceiling with 150° pivoting range.
Application: Improved ergonomics by relieving cable tension, and for ensuring tidiness and avoiding the risk of accidents and injuries due to cables lying on the ground.
Note: For spring return hose reels see No. 080066 to 080079.
08 1106_50B‑4
08 1113_50B‑5
IP 44
08 1198
IP 44
08 1192
Spring-loaded cable reel IP 24
| Type | 10S | 15 | 17S | |
| 08 1198 | – | eShop | – |
08 1192 Safety cable reel
| eShop | – | eShop | ||
| Rated power unrolled | W | 3500 | 2400 | 2400 |
| Nominal voltage | V | 240 | 250 | 250 |
| Length | mm | 406 | 496 | 490 |
| Width | mm | 190 | 192 | 08 1193 190 |
| Height | mm | 313 | 401 | 410 |
Cable class H07RN-F
Cable structure 3G2.5 3G1.5 3G1.5 IP
Material cable Neoprene rubber 24
Cable length m 10 15 17
| Type | 10N | 15 | 15N | 15N2 | 20N | |
| 08 1193 | – | eShop | – | – | – |
08 1194 Cable reel
eShop – – – – 08 1194
08 1195
08 08 1195 Cable reel for F, B, PL, CZ eShop – eShop – –
IP
08 1197 Cable reel – – – eShop eShop 24
Rated power unrolled W 2000 (16 A) 2000 (16 A) 2000 (16 A) 5000 (16 A) 3000 (16 A)
| Nominal voltage | V | 250 | 230 | 250 | 400 | 400 | |
| Width | mm | 185 | 175 | 185 | 208 | 208 | |
| Height | mm | 275 | 390 | 275 | 450 | 450 | 08 1197_15N2 |
Cable class H07RN-F
Cable structure 3G1.5 3G1.5 3G1.5 5G2,5 5G1.5
Material cable Neoprene rubber
Cable length m 10 15 15 15 20
