Compressed air distributor

Distribution blocks made from aluminium (red anodised) for pneumatic hoses. They can be mounted directly on the machine. The clear arrangement of pneumatic hoses increases the safety of work and production, and saves on energy and hose cables thanks to the central supply.

Supplied with: 08 0208 – Distributor block including industrial coupling No. 080230 size 1/4. Without blanking plugs. 08 0209 – Distribution block without nipples, without couplings and without blanking plugs. 08 0208

Note: See No. 080207 V for suitable blanking plugs.

Number of distributor sockets 4

08 0208 Distribution block 08 0209

eShop 08 0209 for compressed air coupling 1/4 inch eShop

Inlet thread in 3/4

Magnetic holder

Magnetic holders with high holding force ensure a safe workplace without tripping hazards. 08 0260 – Anodised blue magnetic stand with 52 kg holding force.

• Prevents accidental slippage.

08 0263 – Rubberised contact surface is oil-resistant and prevents scratching.

• Two separately usable zones (e.g. compressed air gun and hose).

Suitable for: 08 0260 – No. 080122 size AIR and No. 080123 size AIR. 08 0263 – No. 080125 size 100. 08 0263

Type H1 08 0263 Magnetic holder black eShop 08 0260 Magnetic holder anodised blue eShop 08 0260

Cable drums

HEDI® cable drums stand for “Made in Germany” quality and a long service life. The drum body is specially designed to optimally guide the cable. The integrated rotation stop switch prevents accidental rotation of the drum. All cable drums are equipped with thermal cut-out switches.

Cable drums 400 V

IP 44 K2 Sturdy cable drum of high-impact plastic with thermal overload protection. Certified for continuous exterior use and for use in humid environments.

• 400 V CEE input plug 16 A.
• 1 pc. 400 V CEE output plug 16 A with self-closing cover and thermal cut-out switch.
• 2 pcs. 250 V standard Schuko sockets with self-closing covers.
• Inclined 7 degrees for greater ground clearance and to make it comfortable to carry.
• Removable cable holder and guide for optimum cable control.
• Water drainage grooves.
• Easy to mount on a wall.

08 1131/1132 – Compact, high-quality HEDI® all-plastic cable reel with a reel diameter of 250 mm and ergonomic and safety features. 08 1133/1134 – Large and high-quality HEDI® all-plastic cable drum with a drum diameter of 290 mm and numerous ergonomic and safety features. Folding rotary handle for individual clockwise and anticlockwise operation when winding and unwinding.

Note: _20N2 Size 25B2 – On request, we would be pleased to provide text printed on the cable for cable lengths of 100 m or more, subject to an additional charge.

Rated power unrolled W 5500 (16 A)

Cable class H07RN-F H07BQ-F

Cable structure 5G2.5

Material cable Neoprene rubber Armoured cable

Cable length m 20 25
