​Pneumatic straight die grinder
07 9440 – ATA − Pneumatic straight die grinder with 3 mm collets for fine milling, grinding and
engraving. Integral pre-filter.
Size SPM60R – 85 W straight die grinder with high operating comfort with a maximum speed of 60000 _SPM60R
rpm.
■ Slim design for restricted working.
■ Removable collet guard.
Size SPT80R – 63 W straight die grinder with unique motor design without wearing parts in the motor
with a long service life and a maximum speed of 80000 rpm.
_SPT80R
Size SPT100R – 63 W straight die grinder with unique motor design without wearing parts in the motor _SPT100R
with a long service life and a maximum speed of 100000 rpm.
Size ST100 – 40W straight die grinder with high operating comfort and a maximum speed of 100,000
rpm.
07 9442 – ATA − Pneumatic straight die grinder with 6 mm collet.
_ST100
Size S25 – Ergonomic straight die grinder for light to medium applications with one-handed
operation.
■ Push-pull lever for continuous use.
■ Excellent weight/performance ratio.
Size SDM26LR – Straight die grinder for light to medium applications with high user comfort and one-
handed operation.
■ Speed control.
_S25
■ Excellent weight/performance ratio.
Size SM25LR – Powerful straight die grinder for the most demanding applications with high user comfort.
■ Speed control.
■ Smooth start-up.
Size SMX16LR – Extended and ergonomic straight die grinder with two-handed operation.
■ Speed control.
■ Smooth start-up.
Size SMD25LR – Ergonomic straight die grinder with unique vibration damping system. _SDM26LR
■ Smooth start-up.
Application:
07 9440 Size SPT80R–ST100 – Use only oil-free compressed air. Do not add oil!

_SM25LR


_SMX16LR


_SMD25LR
Type SPM60R SPT80R SPT100R ST100 S25 SDM26LR SM25LR SMX16LR SMD25LR
07 9440 eShop eShop eShop eShop – – – – –
03R 03R


Pneumatic straight die grinder
07 9442 – – – – eShop eShop eShop eShop eShop
Output power W 85 63 63 40 190 300 820 820 820
maximum speed min-1 60000 80000 100000 100000 25000 25000 25000 16000 –
maximum air consumption l/min 230 170 170 170 450 570 620 620 620
Connection thread BSP
Compressed air connection in 1/4
Collet ⌀ mm 3 3 3 3 6 6 6 6 6
Weight kg 0.17 0.15 0.15 0.24 0.46 0.52 0.75 1.3 0.8
Operating noise dB(A) 68 68 70 62 68 72 72 75 77
maximum vibration to EN m/s2 <2.5 <2.5 <2.5 < 2.5 3.14 3.14 3.21 3.19 2.27
Length mm 140 135 135 160 164 154 213 345 208

Pneumatic straight die grinder with 1050 W output power and a maximum speed of 18,000 rpm.
Type 3550-180 3550-180ES
Pneumatic straight die grinder collet ⌀
07 07 9453 eShop eShop
03R


_3550-180
6 mm
Output power W 1050
maximum speed min-1 18000
maximum air consumption l/min 1560
Connection thread NPT
Compressed air connection in 1/4
Weight kg 1.2 1.4 _3550-180ES
Operating noise dB(A) 81
maximum vibration to EN m/s2 <2.5
Length mm 248 365
