GBP 57 ​ Deburring and chamfering machine Chamfering machine with smooth start-up and thermal overload protection for machining straight edges, internal and external radii and holes from 22 mm ⌀. Fine adjustment permits light chamfering for deburring and also wide chamfering. With improved cutter head for reduced cutting forces. Size EKF300 – Chamfer 30° − width stepless 0 - 5 mm. Size EKF450 – Chamfer 45° − width stepless 0 - 6 mm. Size EKF452 – Radius R 2.5 mm. Supplied with: Milling head, 3 carbide inserts, swarf hook No. 084520 and transport case. Note: A component edge height of at least 2 mm is necessary to provide guidance. Type EKF300 EKF450 EKF452 07 8121 Deburring and chamfering machine (eShop) eShop (eShop) 07E Power consumption W 1500 maximum speed min-1 6000 Length mm 310 Width mm 138 Height mm 295 AC supply voltage V 230 Chamfer 30° 45° – Radius mm – – 2.5 30° 45° R 2.5 Milling tools ​ 3-edged milling tools, without inserts. Type ZFR300 ZFR450 ZFR452 Milling tool 07 8133 (eShop) (eShop) (eShop) 07E 3-cutter suitable for 078121 Chamfer degrees 30° 45° – Radius mm – – 2.5 _ZFR300 _ZFR450 _ZFR452 Carbide milling insert set ​ Type SHM200 SHM202 Carbide insert set, 3 pieces, SHM 200 07 8128 eShop – 07E for steel Carbide insert set, 3 pieces, SHM 202 07 8131 – eShop 07E for steel radius 2.5 mm suitable for ZFR 300, ZFR 450 ZFR 452 _SHM200 _SHM202 ​Deburring and chamfering machine For producing chamfers and radii on flat materials, sheet metal and containers, internal and external edges, contour profiles and for rounding off holes. 07 8123 – Powerful cordless beveller for optimum preparation of coatings for flexible working in the workshop and on the construction site. Size AKFH18-5AS – Cordless beveller up to 5 mm. 07 8126 – Metal beveller for chamfer heights up to 15 mm for weld seam preparation. 07 8123_AKFH18-5AS ■ Tool-free setting of the cutting depth in 0.1 mm steps. (From 0 mm – 15 mm) ■ Precise adjustment of the chamfer angle. ■ Controlled working by means of large-scale guide plates. ■ Electronic overload protection, soft start and restart protection. B 18 Size KFM9-3RF – Compact beveller for metal, for 45° chamfers and radii from 2 to 3 mm on visible edges. Supplied with: 07 8123 Size AKFH18-5AS – Without battery and charger, 1 machine incl. 45° milling head (without guide roller, without indexable inserts), 3 clamping screws, 1 copper paste, 1 hexagon L-wrench 4 mm, 1 Torx screwdriver TX 15, 1 plastic tool case. 07 8126 – 3 universal carbide inserts, stop roller, 2 screwdrivers, open-ended spanner size 10, bow-type handle, metaBox. Size KFM9-3RF – 2 carbide indexable inserts with 45° chamfer, 2 carbide indexable inserts with radius R2, 2 carbide indexable inserts with radius R3, guide stop, screwdriver, metaBox. 07 8126_KFMV17-15F Note: 07 8123 – The required accessories can be found under No. 078136 – 078138. See No. 073851 – 073866 for suitable rechargeable batteries and chargers. META 07 8126 – The required accessories can be found under No. 078132 and 078134. Type AKFH18-5AS KFMV17-15F KFM9-3RF 07 8123 Cordless beveller (eShop) – – 07 03F handheld NEW Beveller 07 8126 03D – eShop eShop handheld No load speed min-1 2400 – 7500 6200 – 12000 4500 – 11500 Power consumption W – 1700 900 Support table ⌀ mm 98 100 100 Battery voltage V 18 – – 078126_KFM9-3RF Chamfer angle degrees 45 0 – 90 45 Max. chamfer height 45° 5 15 – Radius mm 2.5 – – META Cable length m – 3.9 4 1027
