GBP 57 DIN ISO HPC ≤5µm 6358 7388-1 ​ ombination face mill adapters − DIN ISO 7388-1 C Form (formerly DIN 69871) ADB 30 0835 Taper shank, spigot, and all contact surfaces are ground at the collar. G 2.5 With Balluff/RFID chip bore. 25000 30 0835/0845/0885/0895/0910/0930/0950/0985/0990/1010 – min-1 GARANT −All shanks hard turned (for smooth cutting action!). 30 0837/0875/0975 – All shanks fine bead blasted. Application: ■ With drive key for mills with longitudinal keyway, e. g. DIN 841. ■ With face mill drive ring for face mills with cross keyway, DIN 1880 and cutter heads to DIN 1830. Form Supplied with: Drive key, face mill drive ring, and lock screw. A Optional extras: Pull studs (PS) No. 308600 − 308806, PS wrenches No. 308820 – 308835, G 6,3 18000 Special toggle spanner No. 309840. min-1 Note: Internal cooling available only with suitable tightening screw No. 309861. ≤6µm 30 0875 Spigot ⌀ d1 mm 13 16 22 27 32 40 Combination face mill adapter 30 0835 SK 40 short eShop eShop eShop eShop eShop eShop 31A Form ADB Combination face mill adapter 30 0837 SK 40 short – eShop eShop eShop eShop eShop 32A Form A Combination face mill adapter SK 40 30 0845 – eShop eShop eShop eShop eShop 31A Form ADB A = 100 Combination face mill adapter SK 40 30 0875 – eShop eShop eShop eShop eShop 32A Form A A = 100 SK 40 30 0885 – eShop eShop eShop eShop eShop 31A A = 130 SK 40 30 0895 – eShop eShop eShop eShop eShop 31A A = 160 Combination face mill adapter SK 40 30 0910 – eShop eShop eShop eShop eShop 31A Form ADB A = 200 SK 50 30 0930 – eShop eShop eShop eShop eShop 31A A = 55 SK 50 30 0950 – eShop eShop eShop eShop eShop 31A A = 100 Combination face mill adapter SK 50 30 0975 – eShop eShop eShop eShop eShop 32A Form A A = 100 SK 50 30 0985 – eShop eShop eShop eShop eShop 31A A = 130 Combination face mill adapter SK 50 30 0990 – eShop eShop eShop eShop eShop 31A Form ADB A = 160 SK 50 30 1010 – eShop eShop eShop eShop eShop 31A A = 200 Dimension A (30 0835, 30 0837) mm 55 55 55 55 60 60 ⌀ D mm 27 32 40 48 58 70 L3 mm 18 17 19 21 24 27 L4 mm 23 27 31 33 38 41 Spare milling cutter lock screw No. 309860 / 309861 13 16 22 27 32 40 Spare drive ring No. 309870 13 16 22 27 32 40 Suitable toggle spanner No. 309840 13 16 22 27 32 40 GARANT SOFTCUT® 90° HIGH-PERFORMANCE SHOULDER MILL For top surfaces and straightness on the workpiece. Innovative cutting media. ■ ■ Highly positive surface geometry of the inserts. 30 ■ Optimised chip breakers. 21 5411 971
