GBP 57 L R Cut knurling tools Modular design: Can be used universally as right-hand or left-hand version. Carbide running sleeve for increased wear resistance. Quick tool adjustment by using the adjustment spindle. Cut knurling tool for 1 knurl ​ RAA RAA RBR30° RBL30° RBR45° RBL45° 29 0200_12 1×BR30° 1×BL30° 1×AA 1×AA 1×BL15° 1×BR15° Grub screw in the shank for clearance angle correction. 29 0200 Size 20; 25 – 3-point contact for exact axial positioning. Radial and axial rotational registration for optimum tool guidance. 29 0200_20 Shank size 29 0197 29 0198 29 0200 for knurl ⌀ d1 for knurl width w for knurl bore ⌀ d2 Working range Carbide sleeve, cover disc, screw 29H 29H 29H Cut knurling tool 29 0197 29 0198 29 0197 29 0198 29 0197 29 0198 29 0197 29 0198 29 0197 29 0198 29 0200 29 0200 29 0200 29 0200 29 0200 Sliding headstock lathe universal universal mm mm mm mm mm mm mm mm mm ​ ​ ​ 10 (eShop) (eShop) (eShop) 10 15 3 4 6 8 0 – 15 3 – 50 299920 10 299920 11 299920 5 12 (eShop) eShop eShop 10 15 3 4 6 8 0 – 15 3 – 50 299920 10 299920 11 299920 5 16 (eShop) eShop eShop 10 15 3 4 6 8 0 – 15 3 – 50 299920 10 299920 11 299920 5 20 – – eShop – 25 – 6 – 8 – 10 – 300 – – 299920 1 25 – – eShop – 25 – 6 – 8 – 10 – 300 – – 299920 1 Cut knurling tool for 2 knurls ​ RGE30° RGE45° 2×AA BL/R15° Advantage: ■ Low vibration. 29 0210_12 ■ Adjustment scale and synchronous adjustment spindle for adjusting the workpiece ⌀. ■ Reduced set-up times leading to reduced unit costs. ■ Clearance angle correction of the knurls. ■ Increased wear resistance due to specially hardened surface. ■ For higher feed rates and cutting speeds. 29 0210_25 Shank size 29 0210 for knurl ⌀ d1 for knurl width w for knurl bore ⌀ d2 Working range Carbide sleeve, cover 29H disc, screw Cut knurling tool mm universal mm mm mm mm ​ 10 (eShop) 15 4 8 3 – 50 299920 5 12 eShop 15 4 8 3 – 50 299920 5 16 eShop 15 4 8 3 – 50 299920 5 16X eShop 25 6 8 10 – 250 299920 1 20 eShop 25 6 8 10 – 250 299920 1 25 eShop 25 6 8 10 – 250 299920 1 Cut knurling tool set ​ RAA RAA RBR30° RBL30° RBR45° RBL45° RGE30° RGE45° 29 1×BR30° 1×BL30° 1×AA 1×AA 1×BL15° 1×BR15° 2×AA BL/R45° 29 0219_12 29 0219_20 Shank size mm 12 16 20 25 29 0219 29H Cut knurling tool set eShop eShop eShop eShop Content: Size 12 Size 16 Size 20 Size 25 1 pc. each knurling tool No. 290200 and No. 290210 Size 15×4/0.5; 15×4/0.6; Size 15×4/0.6; 15×4/0.8; Size 25×6/0.8; 25×6/1.0; Size 25×6/0.8; 25×6/1.0; 2 pc. each knurl No. 290261 15×4/0.8 15×4/1.0 25×6/1.5 25×6/1.5 Size 15×4/0.5; 15×4/0.6; Size 15×4/0.6; 15×4/0.8; Size 25×6/0.8; 25×6/1.0; Size 25×6/0.8; 25×6/1.0; 1 pc. each knurl No. 290276 and No. 290281 15×4/0.8 15×4/1.0 25×6/1.5 25×6/1.5 907
