GBP 57 ​ TANGGRIP axial grooving toolholder With two insert pockets. Suitable for: Inserts No. 274422 – 274226. Application: For face grooving. Attention: Please order the assembly key No. 279952 separately. TNFFH-IQ axial grooving toolholder standard ​ w t h5 h1 DAXN-DAXX L WF 27 4204 WB_2 ⌀ range / cut DAXN-DAXX 27 4204 27 4205 Groove width tmax L WB_2 WF h1 h5 26D 26D w TANGGRIP TNFFH-IQ axial grooving toolholder mm right-hand left-hand mm mm mm mm mm mm mm 90-120 (eShop) (eShop) 3 18 150 5.2 4.1 24.8 32 150-500 (eShop) (eShop) 4 32 150 5.2 3.8 24.8 32 150,1-500 (eShop) (eShop) 5 35 150 5.2 3.5 24.8 32 150-700 (eShop) (eShop) 6 35 150 5.2 3.3 24.8 32 ​ TANGGRIP inserts for axial grooving Positive chip breaker. Soft-cutting. Optimal chip control and chip evacuation. Low to medium feed rates. Suitable for: Blade No. 274202 – 274205. Application: For face grooving. Note: The minimum order quantity corresponds to one pack unit quantity (VPE) or a multiple thereof. R w 27 4222 27 4224 27 4226 27 Groove width w / corner radius R 27 4222 27 4224 27 4226 Tolerance groove f 26A 26A 26A width w TANGGRIP TNF-IQ inserts ​ 27 4222 27 4224 27 4226 mm IC808 IC808 IC808 mm mm/rev. mm/rev. mm/rev. 3/0,3 eShop eShop eShop 10 0.05 0.1 – 0.15 0.08 – 0.1 0.06 – 0.1 4/0,25 eShop eShop – 10 0.05 0.1 – 0.15 0.08 – 0.12 – 4/0,4 – – eShop 10 0.05 – – 0.06 – 0.12 5/0,35 eShop eShop – 10 0.05 0.12 – 0.2 0.12 – 0.2 – 5/0,4 – – eShop 10 0.05 – – 0.08 – 0.16 6/0,35 eShop eShop – 10 0.05 0.12 – 0.2 0.12 – 0.2 – 6/0,4 – – eShop 10 0.05 – – 0.08 – 0.16 P M UNI Chip breaker P M GN ​ ​ ​ ​ ​ vc main application m/min 80 – 150 80 – 150 80 – 150 ​ ​ ​ ​ ​ 901
