Режущие и зажимные инструменты Hoffmann Group 2026 - страница 641

GBP 57 POWER s egree MTC CARD a n g ular dequest r Othe ilable on r ava GARANT Softcut® high-performance indexable chamfer mill 90° MTC for AO.T1104.. l Robust plug-in chamfer mill. Insert seat enclosed on several sides for stabilisation of the cutters and to take up the vertical and radial forces. Application: For wide chamfers in steel fabrications. ⌀D ⌀ D1 Outstandingly suitable for roughing and semi-roughing applications. Note: Stepless surfaces are achieved with indexable inserts No. 215431-215487. Use GARANT torque screwdriver TQ No. 211750 size 1.5 with bit No. 674252 size 8IP. γ° b ​ 21 5403 γ° 75 60 45 30 15 h Correction factor fz 1 1.2 1.4 2 3.5 Ltot Angle γ 21 5403 Number of Number of Ltot smallest largest achievable achievable achievable Mounting Feed rate Set of insert screws 21O effective indexable ⌀D ⌀ D1 chamfer chamfer chamfer bore ⌀ per tooth at GARANT Softcut 90° inserts Zeff inserts width b length l height h hmax chamfer mill MTC with bore degrees ​ ​ mm mm mm mm mm mm mm mm ​ 15 eShop 3 9 55 17 70 26.6 27.6 7.2 22 0.4 219799 10 (8IP; 1.5 Nm) 30 eShop 3 9 55 17 65 24.3 28.1 14.2 22 0.2 219799 10 (8IP; 1.5 Nm) 45 eShop 3 9 55 17 56 19.9 28.2 20.2 22 0.14 219799 10 (8IP; 1.5 Nm) 60 eShop 3 9 52 17 45 14.1 28.4 25 16 0.12 219799 10 (8IP; 1.5 Nm) 75 eShop 3 9 60 21 35 7.4 28.7 28.3 16 0.11 219799 10 (8IP; 1.5 Nm) POWER MTC CARD 90° GARANT Softcut® high-performance indexable shoulder mill 90° MTC for AO.T1104.. High precision square shoulder mill with irregular pitch for very smooth cutting, very high precision and cutting power. With special geometry for reduced cutting forces for MTC applications under unstable conditions or for spindles with low drive power. Application: For shoulder milling in large depths, also slotting. General use in all steel materials as well as stainless and acid-resistant steels. Note: Use GARANT torque screwdriver TQ No. 211750 size 1.5 with bit No. 674252 size 8IP. Single-row ​ ap ⌀ D / number of ef- 21 5405 L1 Ltot ⌀ Ds Circular Circular Circular Ramping Set of insert screws 21O Dmin fective cutting edges h6 interpola- interpola- interpola- angle Dmax Z GARANT Softcut 90° tion tion tion αmax shoulder mill milling milling milling MTC ⌀ Dmin ⌀ Dmax ap L1 Ltot 21 Weldon shank mm mm mm mm mm mm mm degrees ​ 14/1 eShop 37 85 16 19 25.3 5 8 219799 11 (8IP; 1.5 Nm) 16/2 eShop 37 85 16 21.7 29.3 7.6 10.5 219799 11 (8IP; 1.5 Nm) ⌀ D DS 18/2 eShop 40 90 20 25.2 33.3 6.7 8.1 219799 11 (8IP; 1.5 Nm) 20/2 eShop 40 90 20 29.1 37.3 6 6.5 219799 10 (8IP; 1.5 Nm) ​ 21 5405 20/3 eShop 40 90 20 29.1 37.3 6 6.5 219799 10 (8IP; 1.5 Nm) 25/3 eShop 49 105 25 38.9 47.3 4.8 4.1 219799 10 (8IP; 1.5 Nm) 25/4 eShop 49 105 25 38.9 47.3 4.8 4.1 219799 10 (8IP; 1.5 Nm) 32/5 eShop 50 110 32 52.8 61.3 4 2.7 219799 10 (8IP; 1.5 Nm) ⌀ D / number of ef- 21 5407 L1 Ltot ⌀ Ds Circular Circular Circular Ramping Set of insert screws 21O fective cutting edges h6 interpola- interpola- interpola- angle Z GARANT Softcut 90° tion tion tion αmax shoulder mill milling milling milling ap ⌀ Dmin ⌀ Dmax ap MTC Plain shank Dmin mm mm mm mm mm mm mm degrees ​ Dmax 16/2 eShop 50 140 16 21.7 29.3 7.6 10.5 219799 11 (8IP; 1.5 Nm) 18/2 eShop 30 140 16 25.2 33.3 6.7 8.1 219799 11 (8IP; 1.5 Nm) Ltot 20/2L eShop 30 160 18 29.1 37.3 6 6.5 219799 10 (8IP; 1.5 Nm) 20/2 eShop 50 160 20 29.1 37.3 6 6.5 219799 10 (8IP; 1.5 Nm) 20/3 eShop 25 160 16 29.1 37.3 6 6.5 219799 10 (8IP; 1.5 Nm) ⌀ D ⌀ DS 25/2L eShop 35 180 20 38.9 47.3 4.8 4.1 219799 10 (8IP; 1.5 Nm) 25/2 eShop 60 180 25 38.9 47.3 4.8 4.1 219799 10 (8IP; 1.5 Nm) ​ 21 5407 25/3 eShop 30 180 16 38.9 47.3 4.8 4.1 219799 10 (8IP; 1.5 Nm) L1 25/4 eShop 25 180 20 38.9 47.3 4.8 4.1 219799 10 (8IP; 1.5 Nm) 641
