GBP 57 NR DIN js12 h6 844 B 3 DIN 25° 1835 B ​Roughing end mill Relief ground knuckle form profile. HSS Centre cutting teeth for plunging. PM 45° Universal end mills for profile milling or for plunging. 19 2445 – For the most demanding metal removal rates. 19 2445 19 2450 – Economy version. HSS Advantage: Compared to multi−flute cutters, better chip evacuation due Co8 45° to larger flutes. 19 2450 L LC ⌀ DC ⌀ DS Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H M M K N ​ ​ ​ ​ ​ ​ 19 2445 138 83 64 64 37 32 23 18 55 110 ● ● ● 19 2450 120 78 55 55 17 14 46 92 ● ● ⌀ js12 DC 19 2445 19 2450 Lc L ⌀ Ds Corner chamfer width 12W 11W at 45° Roughing end mill < 750 N HSS-PM HSS-Co8 fz mm TiAlN TiAlN mm mm mm mm mm 6 eShop eShop 13 57 6 0.3 0.01 7 eShop eShop 16 66 10 0.3 0.01 8 eShop eShop 19 69 10 0.3 0.015 9 eShop eShop 19 69 10 0.4 0.015 10 eShop eShop 22 72 10 0.4 0.025 11 – eShop 22 79 12 0.6 0.025 12 eShop eShop 26 83 12 0.6 0.03 14 eShop eShop 26 83 12 0.6 0.03 15 – eShop 26 83 12 0.6 0.03 16 eShop eShop 32 92 16 0.6 0.04 18 eShop eShop 32 92 16 0.6 0.04 20 eShop eShop 38 104 20 0.6 0.05 25 eShop eShop 45 121 25 0.6 0.055 WR HSS DIN js14 h6 Co8 844 B 3 DIN 36° 1835 B Roughing end mill Relief ground knuckle form profile. Centre cutting teeth for plunging. 45° ■ Wide, precision ground chip flutes. 19 ■ Special chip angle for aluminium and non-ferrous metals. Advantage: Suitable for high machining volumes due to the large flutes. L 19 2520 LC ⌀ DC ⌀ DS Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H M M S N ​ ​ ​ ​ ​ ​ 19 2520 138 83 9 ● ○ ⌀ js14 DC 19 2520 Lc L ⌀ Ds Corner chamfer width 11W at 45° Roughing end mill fz mm HSS-Co8 mm mm mm mm mm 10 eShop 45 95 10 0.3 0.04 12 eShop 53 110 12 0.5 0.05 14 eShop 53 110 12 0.5 0.055 16 eShop 63 123 16 0.5 0.075 18 eShop 63 123 16 0.5 0.075 20 eShop 75 141 20 0.5 0.08 22 eShop 75 141 20 0.5 0.08 25 eShop 90 166 25 0.5 0.09 408
