GBP 57 DIN Type k10 h6 844 B N 30- DIN 4 6 40° 1835 B ​Milling cutter Multi-flute end mill. Eccentric relief ground. HSS 19 1500 – Centre cutting edge geometry for plunging. Co8 90° 19 1520 – For the highest demands in respect to material removal rates. 19 1500 Excellent results when milling dry. Size 6M−25M MID mills: Dimensions to manufacturer’s standard, which lies between HSS DIN 844 short and DIN 844 long. Particularly suitable for PM mould and tool making, as the medium length provides higher 90° rigidity than long series mills to DIN 844. 19 1520 19 1590 – Economy version. HSS PM 90° MID end mill 19 1520 HSS Co8 90° 19 1590 Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H M M K N ​ ​ ​ ​ ​ ​ 19 1500 83 30 25 25 23 55 ● ● 19 1520 138 110 83 64 64 37 32 23 18 55 110 ● ● ● 19 1590 120 78 55 55 17 14 46 92 ● ● ⌀ k10 DC 19 1500 19 1520 19 1590 No. of teeth Z Lc L ⌀ Ds 12W 11W 11W < 750 N End mill fz HSS-Co8 HSS-PM HSS-Co8 19 1500 19 1520 19 1590 ​ ​ ​ ​ mm TiAlN TiAlN ​ ​ ​ mm mm mm mm 2 eShop – – 4 – – 7 51 6 0.003 2,5 eShop – – 4 – – 8 52 6 0.003 3 eShop eShop eShop 4 4 4 8 52 6 0.005 3,5 eShop – – 4 – – 10 54 6 0.005 4 eShop eShop eShop 4 4 4 11 55 6 0.008 4,5 eShop – – 4 – – 11 55 6 0.008 5 eShop eShop eShop 4 4 4 13 57 6 0.01 5,5 eShop – – 4 – – 13 57 6 0.01 6 eShop eShop eShop 4 4 4 13 57 6 0.014 6M – eShop – – 4 – 19 63 6 0.014 6,5 eShop – – 4 – – 16 66 10 0.014 7 eShop eShop eShop 4 4 4 16 66 10 0.014 7,5 eShop – – 4 – – 16 66 10 0.014 8 eShop eShop eShop 4 4 4 19 69 10 0.02 19 8M 8,5 – eShop eShop – – – – 4 4 – – – 28 19 78 69 10 10 0.02 0.02 9 eShop eShop eShop 4 4 4 19 69 10 0.02 10 eShop eShop eShop 4 4 4 22 72 10 0.023 10M – eShop – – 4 – 35 84 10 0.023 10,5 eShop – – 4 – – 22 79 12 0.023 11 eShop – – 4 – – 22 79 12 0.025 11,5 eShop – – 4 – – 22 79 12 0.025 12 eShop eShop eShop 4 4 4 26 83 12 0.028 12M – eShop – – 4 – 40 97 12 0.028 13 eShop eShop eShop 4 4 4 26 83 12 0.028 14 eShop eShop eShop 4 4 4 26 83 12 0.028 15 eShop eShop eShop 4 4 4 26 83 12 0.028 16 eShop eShop eShop 4 6 4 32 92 16 0.034 16M – eShop – – 6 – 48 108 16 0.034 18 eShop eShop eShop 4 6 4 32 92 16 0.034 20 eShop eShop eShop 4 6 4 38 104 20 0.039 20M – eShop – – 6 – 58 122 20 0.039 22 eShop eShop eShop 4 6 4 38 104 20 0.042 24 eShop – – 4 – – 45 121 25 0.042 25 eShop eShop eShop 4 6 6 45 121 25 0.046 25M – eShop – – 6 – 68 144 25 0.046 26 eShop – – 6 – – 45 121 25 0.046 28 eShop – – 6 – – 45 121 25 0.05 30 eShop – – 6 – – 45 121 25 0.05 32 eShop – – 6 – – 53 133 32 0.05 35 eShop – – 6 – – 53 133 32 0.056 40 eShop – – 6 – – 63 155 32 0.06 402
