GBP 57 M B 60° HSS-E- PM DIN 13 ISO 2X 6HX h6 DIN Standard 4 1835 B ≤3×D Synchronised through hole machine taps Sturdy version with lead-in taper and shank to DIN 1835-B. Special geometry for general-purpose use on machines with synchronised spindle drive. The tap is controlled by the synchronising spindle of the machine. Special TiAlN coating for optimum tool life. Can be used with emulsion (fat content minimum 8%). 13 2741 Note: For use on synchronised spindles, the GARANT quick-change tapping chuck L No. 338100 − 338121 with minimum length adjustment (MLA) ensures very high process reliability. ⌀D □ ⌀ DS Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H M M S N ​ ​ ​ ​ ​ ​ 13 2741 40 40 37 35 22 12 7 12 10 35 ● ● ● ● M 13 2741 Thread pitch L ⌀ Ds □ Tapping hole ⌀ 11H Machine tap for synchronised spindles HSS-E-PM Form B 6HX TiAlN mm mm mm mm mm M2,5 eShop 0.45 70 6 4.9 2.05 M3 eShop 0.5 70 6 4.9 2.5 M4 eShop 0.7 70 6 4.9 3.3 M5 eShop 0.8 70 6 4.9 4.2 M6 eShop 1 80 6 4.9 5 M8 eShop 1.25 90 8 6.2 6.8 M10 eShop 1.5 100 10 8 8.5 M12 eShop 1.75 110 12 9 10.2 M14 eShop 2 110 12 9 12 M16 eShop 2 110 12 9 14 M20 eShop 2.5 140 16 12 17.5 M-LH B 60° DIN h9 DIN DIN 13 371 376 4 ≤3×D ≤ M10 ≥ M12 Through hole machine tap left-hand thread 13 2802 – GARANT Vap Tap universal tap – left-hand thread can be used reliably in a wide range of materials. Optimised neck and flute length for 13 13 2802 improved chip evacuation when working on deep threads. HSS-E ISO 2 High-performance HSS-E tool material with higher vanadium content 6H for improved wear resistance. Surface vaporised for reduced edge build-up. 13 2805 – GARANT Master Tap Universal taps, designed for use in a wide spectrum of materials with high process reliability. ​ 13 2805 ■ HSS-E-PM tool material for maximum wear resistance. L HSS-E- ISO 2X ■ Reduced coefficient of friction due to the new high-performance coating. PM 6HX ■ Special geometry for optimum swarf evacuation. ØD Ø DS Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H M M K N ​ ​ ​ ​ ​ ​ 13 2802 18 13 18 15 15 6 6 15 ● ● ● 13 2805 30 35 20 30 30 25 12 8 10 8 20 20 ● ● ● M-LH 13 2802 13 2805 Thread pitch L ⌀ Ds □ Tapping hole ⌀ 13V 11I GARANT Vap Tap GARANT Master Tap machine tap machine tap left-hand thread left-hand thread HSS-E HSS-E-PM 6H 6HX vaporised AlTiX mm mm mm mm mm M3 eShop eShop 0.5 56 3.5 2.7 2.5 M4 eShop eShop 0.7 63 4.5 3.4 3.3 M5 eShop eShop 0.8 70 6 4.9 4.2 M6 eShop eShop 1 80 6 4.9 5 M8 eShop eShop 1.25 90 8 6.2 6.8 M10 eShop eShop 1.5 100 10 8 8.5 M12 eShop eShop 1.75 110 9 7 10.2 M14 – eShop 2 110 11 9 12 M16 eShop eShop 2 110 12 9 14 M20 eShop eShop 2.5 140 16 12 17.5 M24 eShop eShop 3 160 18 14.5 21 281
