GBP 57 M DIN DIN ISO 2 h9 ce 60° HSS-E 352 13 6H 3-pie ≤3×D ≤3×D set Hand tap sets A 13 0400 – Set of three, consisting of taper, 6 second, and plug tap. Taper tap with No. 1 – Taper tap long pilot. Taper tap Second tap Plug tap D 4 No. 2 – Second tap L C ØD 3 No. 3 – Plug tap Pilot pin Ø DS 13 0400 Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H M M S K ​ ​ ​ ​ ​ ​ 13 0400–​13 0430 ○ ● ● ○ ● ○ ● ○ ● ● ○ M 13 0400 13 0410 13 0420 13 0430 Thread pitch L ⌀ Ds □ Tapping hole 11G 11G 11G 11G ⌀ Hand tap set Hand tap, single Taper tap Second tap Plug tap mm mm mm mm mm M2 eShop – – – 0.4 36 2.8 2.1 1.6 M2,5 eShop – – – 0.45 40 2.8 2.1 2.05 M3 eShop ■ eShop eShop eShop 0.5 40 3.5 2.7 2.5 M3,5 eShop – – – 0.6 45 4 3 2.9 M4 eShop ■ eShop eShop eShop 0.7 45 4.5 3.4 3.3 M5 eShop ■ eShop eShop eShop 0.8 50 6 4.9 4.2 M6 eShop ■ eShop eShop eShop 1 50 6 4.9 5 M8 eShop ■ eShop eShop eShop 1.25 56 6 4.9 6.8 M10 eShop ■ eShop eShop eShop 1.5 70 7 5.5 8.5 M12 eShop ■ eShop eShop eShop 1.75 75 9 7 10.2 M16 eShop eShop eShop eShop ■ 2 80 12 9 14 M20 eShop eShop eShop eShop ■ 2.5 95 16 12 17.5 M22 eShop eShop eShop eShop 2.5 100 18 14.5 19.5 M24 eShop eShop eShop eShop ■ 3 110 18 14.5 21 M27 eShop eShop eShop eShop 3 110 20 16 24 M30 eShop eShop eShop eShop 3.5 125 22 18 26.5 M A D C 60° HSS-E DIN DIN ISO 2X h9 352 13 6HX 6 4 3 ≤3×D ≤3×D ce 3-pie Hand tap sets set 13 Set of three, consisting of taper, second, and plug tap. A Taper tap with long pilot. Taper tap Second tap Plug tap Surface nitrided, more resistant to wear. 6 Recommendation: For TOOLOX materials we No. 1 – Taper tap recommend deviating from the DIN D data (see table) by drilling the tapping hole 0.05 to 0.3 mm larger. 4 No. 2 – Second tap Pilot pin C L 3 No. 3 – Plug tap ØD 13 0450 Ø DS Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H H M M S K ​ ​ ​ ​ ​ 13 0450 ○ ● ● ● ○ ● ○ M 13 0450 Thread pitch L ⌀ Ds □ Tapping hole ⌀ 11G Hand tap set nitrided mm mm mm mm mm M2 eShop 0.4 36 2.8 2.1 1.6 M2,5 eShop 0.45 40 2.8 2.1 2.05 M3 eShop 0.5 40 3.5 2.7 2.5 M4 eShop 0.7 45 4.5 3.4 3.3 M5 eShop 0.8 50 6 4.9 4.2 M6 eShop 1 50 6 4.9 5 M8 eShop 1.25 56 6 4.9 6.8 M10 eShop 1.5 70 7 5.5 8.5 M12 eShop 1.75 75 9 7 10.2 M14 eShop 2 80 11 9 12 M16 eShop 2 80 12 9 14 M20 eShop 2.5 95 16 12 17.5 257
