GBP 57 Nominal ⌀ DC 16 4180 ⌀ range Lc L1 L MT Nominal ⌀ DC 16 4180 ⌀ range Lc L1 L MT 12O 12O < 750 N < 750 N Machine reamer f Machine reamer f configurable configurable mm mm mm mm mm ​ mm/rev. mm mm mm mm mm ​ mm/rev. 13 (eShop) 12.61 – 13.2 44 115 182 1 0.15 29 (eShop) 28.01 – 29.05 73 181 281 3 0.25 13,5 (eShop) 13.21 – 13.55 47 122 189 1 0.15 30 (eShop) 29.06 – 30 73 181 281 3 0.3 14 (eShop) 13.56 – 14 47 122 189 1 0.15 31 (eShop) 30.01 – 31.05 75 185 285 3 0.3 14,5 (eShop) 14.01 – 14.5 50 121 204 2 0.15 32 (eShop) 31.06 – 32.05 77 190 317 4 0.3 15 (eShop) 14.51 – 15.05 50 121 204 2 0.2 33 (eShop) 32.06 – 33.05 77 190 317 4 0.3 15,5 (eShop) 15.06 – 15.5 52 127 210 2 0.2 34 (eShop) 33.06 – 34.05 78 194 321 4 0.3 16 (eShop) 15.51 – 16 52 127 210 2 0.2 35 (eShop) 34.06 – 35.05 78 195 321 4 0.3 16,5 (eShop) 16.01 – 16.5 54 132 214 2 0.2 36 (eShop) 35.06 – 36.05 79 200 325 4 0.3 17 (eShop) 16.51 – 17 54 132 214 2 0.2 37 (eShop) 36.06 – 37.05 79 200 325 4 0.3 17,5 (eShop) 17.01 – 17.5 56 137 219 2 0.2 38 (eShop) 37.06 – 38.05 81 204 329 4 0.3 18 (eShop) 17.51 – 18 56 137 219 2 0.2 39 (eShop) 38.06 – 39.05 81 204 329 4 0.3 18,5 (eShop) 18.01 – 18.5 58 142 223 2 0.2 40 (eShop) 39.06 – 40 81 204 329 4 0.35 19 (eShop) 18.51 – 19 58 142 223 2 0.2 41 (eShop) 40.01 – 41.05 82 211 333 4 0.35 19,5 (eShop) 19.01 – 19.5 60 147 228 2 0.2 42 (eShop) 41.06 – 42.05 82 211 333 4 0.35 20 (eShop) 19.51 – 20 60 147 228 2 0.25 43 (eShop) 42.51 – 43.05 83 215 336 4 0.35 21 (eShop) 20.01 – 21.2 62 151 232 2 0.25 44 (eShop) 43.06 – 44.05 83 215 336 4 0.35 22 (eShop) 21.21 – 22.4 64 156 237 2 0.25 45 (eShop) 44.06 – 45 83 215 336 4 0.35 23 (eShop) 22.41 – 23.05 66 160 241 2 0.25 46 (eShop) 45.01 – 46.05 84 219 340 4 0.35 24 (eShop) 23.06 – 24.05 68 167 268 3 0.25 47 (eShop) 46.06 – 47.05 84 219 340 4 0.35 25 (eShop) 24.06 – 25 68 167 268 3 0.25 48 (eShop) 47.06 – 48.05 86 224 344 4 0.35 26 (eShop) 25.01 – 26.05 70 172 273 3 0.25 49 (eShop) 48.06 – 49.05 86 224 344 4 0.35 27 (eShop) 26.06 – 27.05 71 177 277 3 0.25 50 (eShop) 49.06 – 50 86 224 344 4 0.4 28 (eShop) 27.06 – 28 71 177 277 3 0.25 ​ ​ ​ ​ ​ ​ ​ ​ H7 Carbide DIN h6 K10 8093 Carbide machine reamers Long flutes, left-hand helix. Extremely irregular spacing (EU) from size 2. This ensures that the reamed bore is absolutely round and free from chatter marks. Size 1–3,5 – With centring tip. ​ 16 4500 16 Tool material: Sizes 1 − 13 solid carbide. Sizes 14 − 16 with carbide inserts, supported by hard nitrided steel guide chamfers. Application: On stable, low vibration machines. Longer tool life and better dimensional accuracy than HSS reamers. Suitable for/ vc [m/min] ISO code N N N N P P P P P H H H H H M M S N ​ ​ ​ ​ ​ 16 4500 35 30 20 13 10 8 6 10 20 ● ● Nominal ⌀ DC 16 4500 Lc L1 L Number of ⌀ Ds Reaming oversize 11O cutting edges in ⌀ reference Carbide machine reamer Z < 1100 N value f H7 mm mm mm mm ​ mm mm/rev. mm 1 eShop 5.5 14 34 3 1 0.12 0.05 – 0.1 1,2 eShop 7.5 16 38 3 1.2 0.12 0.05 – 0.1 1,5 eShop 8 17 40 3 1.5 0.12 0.05 – 0.1 2 eShop 11 23 49 4 2 0.12 0.05 – 0.1 2,5 eShop 14 27 57 4 2.5 0.12 0.05 – 0.1 3 eShop 15 29 61 6 3 0.12 0.1 – 0.2 3,5 eShop 18 32 70 6 3.5 0.12 0.1 – 0.2 4 eShop 19 43 75 6 4 0.12 0.1 – 0.2 4,5 (eShop) 21 45 80 6 4.5 0.12 0.1 – 0.2 5 eShop 23 52 86 6 5 0.12 0.1 – 0.2 5,5 (eShop) 26 55 93 6 5.6 0.12 0.1 – 0.2 6 eShop 26 55 93 6 5.6 0.12 0.1 – 0.2 6,5 (eShop) 28 62 101 6 6.3 0.12 0.1 – 0.2 7 eShop 31 68 109 6 7.1 0.12 0.1 – 0.2 8 eShop 33 74 117 6 8 0.15 0.1 – 0.2 9 eShop 36 80 125 6 9 0.15 0.1 – 0.2 9,5 (eShop) 36 80 125 6 9 0.15 0.1 – 0.2 10 eShop 38 86 133 6 10 0.15 0.1 – 0.2 11 (eShop) 41 95 142 6 10 0.15 0.1 – 0.2 12 eShop 44 102 151 6 10 0.15 0.1 – 0.2 13 (eShop) 44 104 151 6 10 0.15 0.2 14 eShop 47 109 160 6 12.5 0.15 0.2 15 eShop 50 111 162 6 12.5 0.18 0.2 16 eShop 52 119 170 6 12.5 0.18 0.2 235
