GBP 57 Mounting rails and shelves Colour: RAL 7035 light grey powder coated. Mounting rails ​ For insertion in the cabinets, tilted forwards approx. 16 %. Suitable for: Size 20 – GridLine cabinets with depths 20G. Size 28 – GridLine cabinets with depths 28G. suitable for cabinet depth in G 20 28 97 1525 Mounting rails for shelves with tool sockets, pair (eShop) (eShop) 9GI maximum number of tool carriers 3 4 Safe working load kg 200 97 1525 Shelves ​ 150 kg Suitable for: Installation on mounting rails No. 971525. A 97 1560 – Cabinet width / compartment width 30G (cabinets of width 60G consist of 2 compartments each 30G). 97 1570 – Cabinet width / compartment width 40G (cabinets of width 80G consist of 2 compartments each 40G). 97 1560 for tool shanks SK30 SK40 SK50 VDI20 VDI30 VDI40 C4 C5 C6 C8 Shelf with tool sockets 97 1560 (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) 9GI for cabinet / compartment width 30 G Shelf with tool sockets 97 1570 (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) 9GI for cabinet / compartment width 40 G Height mm 54 Depth mm 135 Number of tool sockets (97 1560) 13 11 5 19 13 12 7 7 11 6 Number of tool sockets (97 1570) 20 15 6 29 19 17 9 9 15 8 Axial spacing A mm 72 76 141 55 71 75 97 97 75 104 for tool shanks HSK40 HSK50 HSK63 HSK80 HSK100 Shelf with tool sockets 97 1560 (eShop) (eShop) (eShop) (eShop) (eShop) 9GI for cabinet / compartment width 30 G Shelf with tool sockets 97 1570 (eShop) (eShop) (eShop) (eShop) (eShop) 9GI for cabinet / compartment width 40 G Height mm 54 Depth mm 135 Number of tool sockets (97 1560) 17 12 9 6 5 Number of tool sockets (97 1570) Axial spacing A mm 22 63 21 71 13 78 8 104 7 116 97 CNC STORAGE FACILITY Tool UNITS and CNC tools can also be stored perfectly and clearly in our upright pull-out frame cabinets: the Tool UNITS can be easily inserted into the Multifix rail for upright cabinets or placed on the storage shelves. Application example: Upright cabinet No. 94 3104_2000 with storage shelf No. 94 3160_6, Application example: Upright Multifix rail No. 94 3170_28, cabinet No. 94 3114_1000 with Tool UNIT No. 97 1000 Multifix rail and Tool UNIT. 561
