GBP 57 No tools are required to clip the wheels to the lower edge profile of the box. Clip-on wheels kit: Treadless wheels ⌀ 100 mm. Load capacity 100 kg with 4 wheels. Suitable for: Euroboxes No. 963420 size 27 − 415. Supplied with: Size 40741 – 2 fixed castors (one each castor “left” and “right”). Size 40742 – 2 castors with parking brake (one each castor ”left” and ”right”). 96 3425 _40741 _40742 Type 40741 40742 96 3425 Clip-on castors set, 2 pieces (eShop) (eShop) 96L possible configuration version 1 1× each size 40741, 40742 possible configuration version 2 – 2× size 40742 Lock set consisting of 2 locks and 2 keys. The sets are available with shared keys (size GL) or individual keys (size VS). Suitable for: Euroboxes No. 963420 size 27 − 415 (size 27 requires only 1 lock). Type GL VS 96 3426 Locks for Eurobox, 2 pieces (eShop) (eShop) 96L ​ 96 3426 ​Large boxes Sturdy stackable transport boxes made from sheet metal with W-post design and angled support. With sturdy folded wall section similar to pipes at the top, sturdy round beading in the wall and floor area as well as dimpled label field for freight stickers (freight stickers can be easily removed from the raised dimpled area). Sturdy stacking and attachment brackets with lifting eyes. Large containers can be lifted by crane using certified crane crossbar in vertical pull chains with hooks. Access height 100 mm. 96 3560 – Solid sides. Colour: 96 3561 – With drop-down side. Mouse grey RAL 7005. 96 Note: Also available in the colours fire red RAL 3000, reseda green RAL 6011 and gentian blue RAL 5010. Please contact us. 96 3560_1200×800 with drop-down side 96 3561_800×500 Usable depth × usable width mm 800×500 1000×800 1200×800 1200×1000 Stackable transport boxes 96 3560 (eShop) (eShop) (eShop) (eShop) 96I with fixed sides Stackable transport boxes 96 3561 (eShop) (eShop) (eShop) (eShop) 96I with drop-down side Height mm 570 670 670 670 Width mm 560 860 860 1060 Depth mm 860 1060 1260 1260 Capacity mm 400 500 500 500 Stacking height maximum mm 500 600 600 600 Drive-in width mm 360 660 660 860 Drive-in depth mm 660 860 1060 1060 Safe working load kg 1000 1000 2000 2000 Stackable load kg 5000 5000 10000 10000 Weight kg 27 42 53 60 473
