GBP 57 Base for GridLine tool cabinets Base of sheet metal for fitting under the cabinet casing. Colour: Light grey RAL 7035, powder-coated. Note: Cabinets must not be moved when loaded. Base for GridLine tool cabinets, casing depth 24G ​ 95 8060 – Base 50 mm tall. 95 8065 – Base 100 mm tall with removable fascia (front and back). 95 8066 – Base 150 mm tall with removable fascia (front and back). Suitable for: Tool cabinets No. 930505 – 930735. Note: 95 8065/8066 – For safety reasons, the base size 24 is not approved for transport using a pallet truck. 95 8060 Cabinet casing in G 24 30 40 Base depth 24G, 95 8060 9GK (eShop) (eShop) (eShop) Height 50 mm Base with removable fascia, depth 24G, 95 8065 9GK (eShop) (eShop) eShop Height 100 mm 95 8065 Base with removable fascia, depth 24G, 95 8066 9GK (eShop) (eShop) (eShop) Height 150 mm Height (95 8060) mm 50 Height (95 8065) mm 100 Height (95 8066) mm 150 Width mm 600 750 1000 Depth mm 600 95 8066 Suitable for housing width in G Suitable for housing depth in G 24 30 24 40 95 Application example Base for GridLine tool cabinets, casing depth 28G ​ 95 8080 – Base 50 mm tall. 95 8085 – Base 100 mm tall with removable fascia (front and back). 95 8086 – Base 150 mm tall with removable fascia (front and back). Suitable for: Tool cabinets No. 931005 - 932122, Office station No. 948800. Note: Size 60 – Suitable for drawer cabinets only, cannot be used for sliding door cabinets No. 932128 and 932130. 95 8085/8086 – For safety reasons, the base size 24 is not approved for transport using a pallet truck. 95 8080 Cabinet casing in G 24 30 40 50 60 Base depth 28G, 95 8080 9GK (eShop) (eShop) (eShop) (eShop) (eShop) Height 50 mm Base with removable fascia, depth 28G, 95 8085 9GK (eShop) eShop eShop eShop eShop 95 8085 Height 100 mm Base with removable fascia, depth 28G, 95 8086 9GK (eShop) (eShop) (eShop) (eShop) (eShop) Height 150 mm Height (95 8080) mm 50 Height (95 8085) mm 100 Height (95 8086) mm 150 Width mm 600 750 1000 1250 1500 95 8086 Depth mm 700 Suitable for housing width in G 24 30 40 50 60 Suitable for housing depth in G 28 459
