GBP 57 20×20 G 30×20 G 40×20 G 50×20 G 60×20 G 80×20 G 30×28 G 40×28 G 60×28 G 80×28 G 500×500 mm 750×500 mm 1000×500 mm 1250×500 mm 1500×500 mm 2000×500 mm 750×700 mm 1000×700 mm 1500×700 mm 2000×700 mm GridLine rack panels for plain sheet metal doors ​ Of sheet metal for mounting hooks and open storage bins. The rack panels are screwed to the inside of swing doors, using the fastenings provided. Only for cabinets with plain sheet metal swing doors of minimum size 750 mm wide and 1000 mm high. Cabinets with a height of 2000 mm can take 2 panels per swing door. Load capacity per door: 10 kg. Size L – With □ 9×9 mm at 37 mm intervals for mounting accessories for perforated panels (Group 95). Size S – With slots to accept open storage bins No. 963321. Colour: RAL 7016 anthracite, powder coated. Note: ■ Open storage bins and wide projecting tools cannot be inserted at the height of storage shelves. ■ Suitable only for GridLine cabinets with swing doors. 94 Installation example with rack panels. 94 0705_S 94 0705_L Type L S 94 0705 Rack panel for plain sheet metal doors (eShop) (eShop) 9GI Height mm 800 Width mm 250 Thickness mm 28 GridLine perforated panel for cabinets ​ Zn With 3-sided galvanised perforated panel of sheet steel with □9×9 mm holes on a 37 mm grid for mounting hooks and holders, together with perforated panel accessories. These can be found in Group 95. Perforated panels can be fitted to modular cabinets in 1000 mm (40G) and 2000 mm (80G) widths. The height is 575 mm, so that up to 3 perforated panels can be fitted one above another in a 2000 mm high cabinet. Suitable for: Cabinets No. 940081 – 940103, No. 940111 – 940113 No. 940205 – 940217, No. 940841 – 940849, No. 940905 – 940907. Note: Do not bend the perforated panels repeatedly at the perforations. ​ 94 0710 Application example for cabinet width in G 40 94 0710 Perforated panel for cabinets (eShop) 9GI Height mm 575 Safe working load kg 60 284
