GBP 57 24×24 G 30×24 G 40×24 G 24×28 G 30×28 G 40×28 G 50×28 G 60×28 G 600×600 mm 750×600 mm 1000×600 mm 600×700 mm 750×700 mm 1000×700 mm 1250×700 mm 1500×700 mm 25 Tool cabinet casing 30×24 G Tool cabinet casing in 30×24G, suitable for drawers 26×20G. For drawer runner mountings at 25 mm intervals. The casing can be locked centrally with a cylinder lock. Colour: RAL 7035 light grey powder coated. Note: When fitting out the tool cabinet with drawers, check that the sum of the heights of individual drawer fronts corresponds to the usable height for the cabinet. 93 ​ _1000 Height mm 700 800 900 1000 93 0625 9GK Tool cabinet casing for drawers 26×20G (eShop) (eShop) (eShop) (eShop) Height mm 700 800 900 1000 Width mm 750 Depth mm 600 Width in G 30 Depth in G 24 Usable height mm 600 700 800 900 Weight kg 33 35 38 40 100% 26G 20G Drawers 26×20 G 100% full extension drawers with differential runners. Aluminium handle with labelling strips that can be exchanged and rewritten. Slots at 25 mm intervals to take slotted dividers (from drawer front height 75 mm). 93 0633/0634 – Load capacity 75 kg. 93 0634/0636 – With individual drawer release system prevents the opening of drawers during transport. Absolutely necessary for all roller cabinets. 93 0635/0636 – Load capacity 200 kg. Colour: Drawer body RAL 7035 light grey, drawer fronts RAL 7016 anthracite, powder-coated. Drawer body not configurable, always RAL 7035 light grey. Supplied with: Drawers each complete with 1 pair drawer runner rails. 93 0633_50 93 0633_150 93 0633_300 Drawer front height mm 50 75 100 125 150 200 250 300 75 kg Drawer, 93 0633 9GK 26×20G (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) 75 kg Drawer with one-handed individual drawer 75 kg 93 0634 9GK release system, 26×20G (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) 75 kg 200 kg Drawer, 93 0635 9GK 26×20G – (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) 200 kg Drawer with one-handed individual drawer 200 kg 93 0636 9GK release system, 26×20G – (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) 200 kg Usable height mm 25 50 75 100 125 175 225 275 Usable width mm 650 Usable depth mm 500 Usable width in G 26 Usable depth in G 20 Weight kg 10 12 13 13 15 16 17 19 226
