INDEXABLE SIDE MILLING CUTTERS & CARBIDE INSERTS INDEXABLE SIDE MILLING CUTTERS FOR SNCQ INSERT Features : • Radial and Axial run-out less than 0.02mm. • Inserts to be hold by swiss SFS high strength screws. • Made of quality alloy steel and hardness HRC45-HRC48. • High precision for quality surface. Size(mm) r B L, Order No. dm 251-61-002 251-61-004 251-61-006 100 125 251-61-008 251-61-010 160 251-61-012 251-61-014 251-61-016 100 125 251-61-018 251-61-020 160 251-61-022 251-61-024 251-61-026 100 251-61-028 125 160 251-61-030 251-61-032 100 251-61-034 125 251-61-036 160 Insert not included r ja KL£ - 1 p. B 6 6 6 6 6 7 7 7 7 7 8 8 8 8 8 8 8 8 10.4 10.4 12.4 14.4 16.4 10.4 10.4 12.4 14.4 16.4 10.4 10.4 12.4 14.4 16.4 12.4 14.4 16.4 No .of teeth Insert Screw Torx wrench 3*2 4*2 5* 2 6*2 8*2 3*2 4* 2 5* 2 6*2 8*2 3*2 4*2 5* 2 6*2 8*2 5* 2 6*2 8*2 SNCQ123503N SNCQ123503N SNCQ123503N SNCQ123503N SNCQ123503N SNCQ120403N SNCQ120403N SNCQ120403N SNCQ120403N SNCQ120403N SNCQ124503N SNCQ124503N SNCQ124503N SNCQ124503N SNCQ124503N SNCQ120503N SNCQ120503N SNCQ120503N ST4073-91F ST4073-91F ST4073-91F ST4073-91F ST4073-91F ST409-91F ST409-91F ST409-91F ST409-91F ST409-91F ST409-91F ST409-91F ST409-91F ST409-91F ST409-91F ST409-91F ST409-91F ST409-91F WT15 WT15 WT15 WT15 WT15 WT15 WT15 WT15 WT15 WT15 WT15 WT15 WT15 WT15 WT15 WT15 WT15 WT15 Recommended cutting data : Application Surface speed Vc ( m/min) Medium cutting Feed per tooth fz(mm) Cutting depth ap(mm) Surface speed Vc(m/min) Rough cutting Feed per tooth fz(mm) Cutting depth ap(mm) Steel Stainless Steel Cast iron Non ferrous metal High temperature alloy 200-100 0.05-0.12
