INDEXABLE END MILLS & CARBIDE INSERTS 45 ° INDEXABLE END MILLS FOR SPMT 0903 INSERT Features : DIN 1835B 4 / Kr • Radial and Axial run-out less than 0.02mm. • Inserts to be hold by swiss SFS high strength screws . • Made of quality alloy steel and hardness HRC 45-HRC48. • Used for both of milling and countersinking . Kr=45 ° 45 ° Z o E " O T3 a L1 L Size(mm) Order No. 241-60-001 241-60-002 241-60-003 241-60-004 241-60-005 241-60-006 Insert not included No .of teeth EM45 -10SP09 EM45 -12SP09 EM45-16SP09 EM45 -20SP09 EM45 -25SP09 EM45 -32SP09 Insert Screw Torx wrench Weight (Kg) SPMT0903.. SPMT0903.. SPMT0903.. SPMT0903.. SPMT0903.. SPMT0903.. C030A07S C030A07S C030A07S C030A07S C030A07S C030A07S T9 T9 T9 T9 T9 T9 0.1 0.2 0.3 0.5 0.9 1.0 Recommended cutting data : Application Steel Stainless Steel Cast iron Non ferrous metal High temperature alloy Rough cutting Finish cutting Medium cutting Surface speed | Feed per tooth | Cutting depth | Surface speed | Feed per tooth | Cutting depth | Surface speed | Feed per tooth | Cutting depth Vc (m/min) Vc(m/min) Vc(m/min) ap (mm) ap(mm) ap(mm) fz(mm) fz(mm) fz(mm) 250-80 190-70 0.05- 0.10 0.05- 0.10 0.1-1.0 0.1-1.0 200-70 150-40 0.10-0.25 0.10-0.25 10-2.5 1.0-2.5 150-55 0.20-0.35 <4 SOLID CARBIDE INSERT SPMT 0903 aS s Size (mm) Order No. Model Application Grade 230-60-101 SPMT090308EN-EM Steel EP2220 r 9.525 3.18 11° 3.4 www. harlingentools . com 0.8 140
