Spantreppe, extra stabile Ausführung
grooving, boring and profiling boring and profiling D min. 1.0 - 7.0 mm
starting at Ø 0.2 mm with through coolant, chipbreaker and extra solid construction
| Rechts (R): wie gezeichnet Links (L): spiegelbildlich R L1 7° 6° f a R L1 t max. f a 7° 6° | L | right lefth | hand (R): and versi d h6 D mi D mi | as shown on (L): mir n. ≥ 3.0 n. < 3.0 | ror image D min. D min. mm mm inner throu | D min. ≥ 3.0mm D min. < 3.0mm e Kühlmittelzufuhr gh coolant | ||
| Bestellnummer part number R f Abmessungen in mm | a | L | L1 | t max. dime | D min. nsions in | Ø d h6 mm | K10F CN45F AL41F P18C | Klemmhalter Typ toolholder type |
| R/L X050.1-5R05 0.05 0.45 | 0.9 | 20 | 5 | 0.03 | 1.0 | 4.0 | | |
| R/L X050.15-7R10 0.1 0.65 | 1.35 | 21 | 7 | 0.05 | 1.5 | 4.0 | | |
| R/L X050.2-5R15 0.15 0.9 | 1.8 | 19 | 5 | 0.1 | 2.0 | 4.0 | | |
| R/L X050.2-10R05 0.05 0.9 R/L X050.2-10R15 0.15 0.9 R/L X050.2-15R15 0.15 0.9 | 1.8 1.8 1.8 | 24 24 29 | 10 10 15 | 0.1 0.1 0.1 | 2.0 2.0 2.0 | 4.0 4.0 4.0 | | 640.∙∙∙ 645.∙∙∙ ∙∙∙.4 |
| R/L X050.3-10R05 0.05 0.7 R/L X050.3-10R20 0.2 0.7 | 2.7 2.7 | 24 24 | 10 10 | 0.15 0.15 | 3.0 3.0 | 4.0 4.0 | | |
| R/L X050.3-16R05 0.05 0.7 | 2.7 | 30 | 16 | 0.15 | 3.0 | 4.0 | | |
| R/L X050.3-16R10 0.1 0.7 | 2.7 | 30 | 16 | 0.15 | 3.0 | 4.0 | | |
| R/L X050.3-16R20 0.2 0.7 ↳ ... | 2.7 | 30 | 16 | 0.15 | 3.0 | 4.0 | |
