Bestellnummer part number Ø DS Ød t max. t max.h Schneidenzahl number of DS cutting edges Spannschraube screw d Schraubenschlüssel wrench Anzugs- drehmoment torque für Schneidplatten for insert SYSTEM 500 Typ 581 Nut- und Trennfräsen Messerkopf D min. 64 mm t max. 5.0 groove milling milling cutter D min. 64 mm and slotting cutter t max. 5.0 h Abmessungen in mm dimensions in mm 581.0063.05-D 63 22 5 14.2 5 581.0080.08-D 80 27 5 16.2 8 85.818 TR20 3.0 Nm 514.∙∙∙ 581.0100.10-D 100 32 5 20.2 10 Achtung: attention: Messerkopf ist ohne Schneidplatten! Milling cutter is without inserts! Bestellbeispiel: order-example: 519 581.0063.05-D 581.0063.05-D
