grooving, boring and profiling type grooving, D min. 8 - 16 mm
grooving and profiling full radius R 0.4 - 2.0 full radius
| Rechts (R): wie gezeichnet Links (L): spiegelbildlich f D min. b R t max. | d s Klemmh toolhold | righth leftha alter S er fac | and (R): as s nd version ( tirnseite e | hown L): mirror | image |
| Bestellnummer part number b +0.05 b (inch) R Abmessungen in mm | f s | d dimen | t max. sions in mm | D min. | K10F AL41F P18C Klemmhalter Typ toolholder type |
| R/L S08.008R04 0.80 0.40 R/L S08.012R06 1.20 0.60 R/L S08.U15R08 1.57 0.062" 0.78 | 4.8 3.3 4.8 3.3 4.8 3.3 | 6.0 6.0 6.0 | 1.0 1.0 1.0 | 8 8 8 | 608 |
| R/L S08.018R09 1.80 0.90 R/L S08.020R10 2.00 1.00 | 4.8 3.3 4.8 3.3 | 6.0 6.0 | 1.0 1.0 | 8 8 | |
| R/L S09.008R04 0.80 0.40 R/L S09.010R05 1.00 0.50 | 5.5 3.5 5.5 3.5 | 6.2 6.2 | 1.6 1.6 | 9 9 | |
| R/L S09.012R06 1.20 0.60 R/L S09.018R09 1.80 0.90 | 5.5 3.5 5.5 3.5 | 6.2 6.2 | 1.6 1.6 | 9 9 | 609 |
| R/L S09.020R10 2.00 1.00 ↳... | 5.5 3.5 | 6.2 | 1.6 | 9 | |
177 RS08.008R04/AL41F RS08.008R04/AL41F
