grooving, boring and profiling type grooving, D min. 16 mm

for circlips DIN 471 / 472 and grooving

Rechts (R): wie gezeichnet Links (L): spiegelbildlich f D min. b t max.			d s Kle too	mmha lholde	righthand (R): as sho lefthand version (L): lter Stirnseite r face	wn mirror image m Beispielzeic exemplary	hnung application
Bestellnummer part number Nut-Maß m groove dim. m DIN 471 / DIN 472 Abmessungen in mm	b +0.03	b (inch)	f	s	d t max. dimensions in mm	D min. K10F AL41F P18C	Klemmhalter Typ toolholder type
R/L S016.0070 0.7 R/L S016.0080 0.8 R/L S016.0090 0.9 R/L S016.0110 1.1 R/L S016.0117 - - R/L S016.0130 1.3 R/L S016.0150 - - R/L S016.0157 - - R/L S016.0160 1.6 R/L S016.0185 1.85 ↳...	0.73 0.83 0.93 1.20 1.17 1.40 1.50 1.57 1.70 1.95	0.046 0.062	10.2 10.2 10.2 10.2 “ 10.2 10.2 10.2 “ 10.2 10.2 10.2	5.2 5.2 5.2 5.4 5.4 5.4 5.4 5.4 5.4 5.4	11 1.2 11 1.3 11 1.5 11 4.3 11 4.3 11 4.3 11 4.3 11 4.3 11 4.3 11 4.3	16  16  16  16   16  16   16   16  16   16  	616
