Tooling by DIJET Indexable Tools QM MAX QXPTyPE ■ RECOMMENDED CUTTING CONDITIONS / LOW DEPTH OF CUT AND HIGH FEED ● ZPMT100320ZER insert Tool dia. (mm) Work Insert 63/66 Materials Grades No. of teeth 8N ℓ ap ae n Vf (mm) (mm) (mm) (min-1) (mm/min) ~200 0.4 ~50 860 4,130 Carbon steel 250 0.3 ~50 860 4,130 S50C, S55C JC5118 (C50, C55) 300 0.25 ~50 770 3,350 (JC8050) Below 250HB 350 0.2 ~50 770 3,350 400 0.15 ~50 640 2,640 ~200 0.4 ~50 810 3,890 Die steel 250 0.3 ~50 810 3,890 SKD61, SKD11 JC5118 (1.2344, 1.2379) 300 0.25 ~50 730 3,150 (JC8050) Below 255HB 350 0.2 ~50 730 3,150 400 0.15 ~50 650 2,490 ~200 0.4 ~50 810 3,890 Mold steel 250 0.3 ~50 810 3,890 HPM7, PX5, P20 JC8050 (1.2311, P20) 300 0.25 ~50 730 3,150 (JC5118) 30-36HRC 350 0.2 ~50 730 3,150 400 0.15 ~50 650 2,490 ~200 0.4 ~50 760 4,260 Grey & Nodular 250 0.35 760 4,260 ~50 cast iron FC, FCD JC5118 300 0.3 ~50 680 3,450 (GG, GGG) Below 300HB 350 0.25 ~50 680 3,450 400 0.2 ~50 610 2,730 ~200 0.4 ~50 860 4,130 250 0.3 ~50 860 4,130 Stainless steel SUS304 JC8050 300 0.25 ~50 770 3,350 Below 250HB 350 0.2 ~50 770 3,350 400 0.15 ~50 640 2,640 ~200 0.3 ~50 300 960 250 0.25 ~50 300 960 Titanium alloy JC5118 (Ti-6Al-4V) 300 0.2 ~50 280 900 (JC8050) 350 0.15 ~50 280 900 400 0.1 ~50 250 800 ~200 0.3 ~50 150 350 250 0.25 ~50 150 350 Inconel JC5118 300 0.2 ~50 130 310 (INCO718) (JC8050) 350 0.15 ~50 130 310 400 0.1 ~50 100 240 ℓ: Overhung length, ap: Axial depth of cut, ae: Radial depth of cut, n: Spindle speed, Vf: Feed speed ■ NOTE 1) The cutting parameters to be adjusted according to the machine rigidity or work rigidity. 2) In case chatter occurrs, recommend to reduce depth of cut or feed speed. 3) If machine does not have enough power, recommend to reduce depth of cut first and reduce spindle speed and feed speed. C070 4) Use air blow to flush the chips out.
