Tooling by DIJETTooling by DIJETTooling by DIJET
Reciprocating Milling Up & Down Milling Reciprocating Milling Up & Down Milling C MD C MD
W Lf W Lf ■■■ BODY Arbor B193
| Cat. No. | Stock | No. of flutes | With/Without Coolant hole | φDc | Lf | Dimensio φDb | ns(mm) MD | C | W |
| MPF-2030-M16 | □ | 2 | -- | 30 | 50 | 28 | M16 | 12.5 | 22 |
| MPF-2033-M16 | □ | 2 | -- | 33 | 50 | 32 | M16 | 12.5 | 22 |
| MPF-3040-M16 | □ | 3 | ● | 40 | 50 | 32 | M16 | 13 | 26 |
| ote)1. Please refe 2. All cutters | r page are su | B177 pplied | for recommen without inserts | ded cutting . | conditions. | Clam DS | p Screw W-307H Re | commended Torque (N・m) 1.8 |
3. Please refer page B009 for recommended tightening torque.
INSERTS
DPGT0903-W3 DPGT0903-W3 JC8003 JBN500
55 ° 55 55 55 88 8 R0.R0. R0. 8 R0.
| R0.8R0.8 | ° | R0.8R0.8 | ° |
| 3.18 | 11 ° | 3.18 | 11 ° |
| 3.18 | 11 | 3.18 | 11 |
| PVD coated | CBN | ||
| Cat. No. | |||
| JC8003 (Semi-finishing to Finishing) | JBN500 (Superfinishing) |
DPGT0903-W3 G ●●● ●●□
10 inserts per case, but JBN500: 1 piece per case. ■■■ PARTS
| Clamp screw (A) | Wrench for (A) & (B) | Cartridge | Screw for radial adjustment (B) | Set bolt | Wrench for setbolt |
| DSW-307H | A-10SD | SDGPR09CA-PFC | RSW-05008 | HCS5-10 | LW-040 |
| ●： | □： | ● Standard stock items ◎：□: Stock in Japan ○：○: Soon to be deleted※ | B053B179 | |||
| ●： | □： | ◎： | ○： | ※ | B053B053 |
