® Mini Mill-Thread FMTI Multi Flute Carmex has designed a unique line of solid carbide thread milling tools FMTI for increased productivity and high performance. Large number of flutes enables to achieve significant shorter machining time. Carbide grade: MT6 Ultra-Fine carbide grade with high hardness and toughness provides an excellent solution for machining steels, stainless steels, and super alloys Ni or Ti base. With a universal PVD multi-layer coating, provides high heat and wear resistance. ISO Tools for Internal Thread Grade P M K N S H MT6      ≤ 58 HRc Pitchmm M Coarse MFine Ordering Code d D No. ofFlutes I L ThreadDepth 0.35 M1.6, M1.8 M2 FMTI 03012 E3 0.35 ISO 3 1.20 5 3.6 38 2xD1 0.4 M2 FMTI 03016 F4 0.4 ISO 3 1.55 6 4.4 38 2xD1 0.45 M2.5 FMTI 0302 F5 0.45 ISO 3 1.95 6 5.5 38 2xD1 0.5 M3 M4, M5 FMTI 03024 F6 0.5 ISO 3 2.40 6 6.5 38 2xD1 0.7 M4 FMTI 04032 F8 0.7 ISO 4 3.20 6 8.7 50 2xD1 0.8 M5 FMTI 0404 G10 0.8 ISO 4 4.00 7 10.8 50 2xD1 1.0 M6 M8 FMTI 06048 G13 1.0 ISO 6 4.80 7 13.0 57 2xD1 Order example: FMTI 03024 F6 0.5 ISO MT6 UN Tools for Internal Thread Grade P M K N S H MT6      ≤ 58 HRc PitchTPI UNC UNF Ordering Code d D No. ofFlutes I L ThreadDepth 72 1 FMTI 03015 E4 72 UN 3 1.45 5 4.1 38 2xD1 56 2 3 FMTI 03017 F4 56 UN 3 1.65 6 4.8 38 2xD1 40 4 FMTI 03021 F6 40 UN 3 2.10 6 6.3 38 2xD1 32 10 FMTI 04038 F10 32 UN 4 3.80 6 10.5 50 2xD1 28 1/4 FMTI 06052 G13 28 UN 6 5.20 7 13.6 57 2xD1 Order example: FMTI 03017 F4 56 UN MT6 First choice Alternative B09-17
