Каталог ARNO монолитный осевой инструмент - страница 74

VHM-Schaftfräser AFA Solid carbide end-mill Fraise carbure monobloc à tige AFA50116-… 1 Schneide, mittellange Ausführung / 1 flute, mid-length design / 1 dent, version 98 – 106 mi-longue HA AFA 30° 1 Feinstkorn Ultra micro granulation dA d Grain ultra fin l1 l PG 24 beschichtet coated revêtu Schaft DIN 6535HA TiCN Shank d dA l1 l Tige -0,03 h6 AFA50116-020 2 3 8 50  AFA50116-030 3 3 12 50  AFA50116-040 4 4 15 60  AFA50116-050 5 5 17 60  AFA50116-060 6 6 20 65  AFA50116-080 8 8 22 65  AFA50116-100 10 10 25 75  AFA50116-120 12 12 30 80    Hauptanwendung Main application Application principale  Nebenanwendung Secondary application Application secondaire 74 VHM- / PM-HSS Werkzeuge | Solid carbide- / PM-HSS Tools | Outils carbure monobloc / PM-HSS Alle Angaben in mm / Dimensions in mm / Toutes les dimensions en mm
