HydraulicShrink FitER ColletEnd Mill HolderShell MillPower MillingMorse TaperSK SlimSynchroTappingTappingFace MillNC Drill ChuckBoringAccessory ChuckHolderChuck& Side Lock ArborArborChuckArborChuckTapping ChuckER ChuckChuckArbor& Other Tool HoldersSystem& Others & OthersSystem& Other Tool HoldersArborChuckER ChuckTapping ChuckChuckArborChuckArbor& Side Lock ArborChuckHolderChuck AccessoryBoringNC Drill ChuckFace MillTappingTappingSynchroSK SlimMorse TaperPower MillingShell MillEnd Mill HolderER ColletShrink FitHydraulic ER COLLET CHUCK ER COLLET CHUCK ГАЙКИ ER PART ГАЙКИ ER PART ER NUSS ER NUSS ER ÉCROU ER ÉCROU ER DADO ER DADO ER TUERCA ER TUERCA DIN 6499/ISO 15488 ■ SQ-ER (Standard : Hex.) Unit : mm ■ XSQ-RT (Sealing Disk Type : Hex.) Unit : mm MODEL No. EDP No. THREAD Dia. LENGTH MODEL No. EDP No. THREAD Dia. LENGTH SQ-ER11 P2700006 M14×0.75 19.0 12.0 XSQ-RT16 P2777009 M22×1.50 28.0 22.5 SQ-ER16 P2700001 M22×1.50 28.0 18.0 XSQ-RT20 P2777010 M25×1.50 34.0 24.0 SQ-ER20 P2700002 M25×1.50 34.0 19.5 ■ XSQ-RUT (Sealing Disk Type : Round) Unit : mm ■ SQ-ER (Standard : Round) Unit : mm MODEL No. EDP No. THREAD Dia. LENGTH MODEL No. EDP No. THREAD Dia. LENGTH XSQ-RUT16 P2777011 M22×1.50 32.0 22.5 SQ-ER25 P2700003 M32×1.50 42.0 20.5 XSQ-RUT20 P2777012 M25×1.50 35.0 24.0 SQ-ER32 P2700004 M40×1.50 50.0 23.0 XSQ-RUT25 P2777013 M32×1.50 42.0 25.0 SQ-ER40 P2700005 M50×1.50 63.0 26.0 XSQ-RUT32 P2777014 M40×1.50 50.0 27.5 SQ-ER50 P2700007 M64×2.00 78.0 35.0 XSQ-RUT40 P2777015 M50×1.50 63.0 30.5 ■ XSQ-R (Standard : Hex.) Unit : mm ■ XSQ-RSU (Sleeve Bearing Type) Unit : mm MODEL No. EDP No. THREAD Dia. LENGTH MODEL No. EDP No. THREAD Dia. LENGTH XSQ -R11 P2777002 M14×0.75 19.0 12.0 XSQ-RSU16 P2777016 M22×1.50 32.0 18.0 XSQ -R16 P2777003 M22×1.50 28.0 18.0 XSQ-RSU20 P2777017 M25×1.50 35.0 20.0 XSQ -R20 P2777004 M25×1.50 34.0 19.5 XSQ-RSU25 P2777018 M32×1.50 42.0 20.5 XSQ-RSU32 P2777019 M40×1.50 50.0 23.0 XSQ-RSU40 P2777020 M50×1.50 63.0 26.0 ■ XSQ-RU (Standard : Round) Unit : mm MODEL No. EDP No. THREAD Dia. LENGTH XSQ-RU25 P2777005 M32×1.50 42.0 20.5 ■ XSQ-RST (Sleeve Bearing / Sealing Disk Type : Hex.) Unit : mm XSQ-RU32 P2777006 M40×1.50 50.0 23.0 MODEL No. EDP No. THREAD Dia. LENGTH XSQ-RU40 P2777007 M50×1.50 63.0 26.0 XSQ-RST16 P2777021 M22×1.50 28.0 22.5 XSQ-RU50 P2777008 M64×2.00 78.0 35.0 XSQ-RST20 P2777022 M25×1.50 34.0 24.5 ■ XSQ-RSUT (Sleeve Bearing / Sealing Disk Type : Round) Unit : mm MODEL No. EDP No. THREAD Dia. LENGTH XSQ-RSUT16 P2777023 M22×1.50 32.0 22.5 XSQ-RSUT20 P2777024 M25×1.50 35.0 24.5 XSQ-RSUT25 P2777025 M32×1.50 42.0 25.0 XSQ-RSUT32 P2777026 M40×1.50 50.0 27.5 XSQ-RSUT40 P2777027 M50×1.50 63.0 30.5 098 Phone: +82-32-526-0909, www.yg1.kr, E-mail: yg1@yg1.kr Phone: +82-32-526-0909, www.yg1.kr, E-mail: yg1@yg1.kr 099
