Каталог YG-1 инструментальная оснастка - страница 48

D1 D2 D1 DD1 HydraulicShrink FitER ColletEnd Mill HolderShell MillPower MillingMorse TaperSK SlimSynchroTappingTappingFace MillNC Drill ChuckBoringAccessory ChuckHolderChuck& Side Lock ArborArborChuckArborChuckTapping ChuckER ChuckChuckArbor& Other Tool HoldersSystem& Others & OthersSystem& Other Tool HoldersArborChuckER ChuckTapping ChuckChuckArborChuckArbor& Side Lock ArborChuckHolderChuck AccessoryBoringNC Drill ChuckFace MillTappingTappingSynchroSK SlimMorse TaperPower MillingShell MillEnd Mill HolderER ColletShrink FitHydraulic ER COLLET CHUCK ER COLLET CHUCK ПЛАВАЮЩИЕ ПАТРОНЫ ER (ТОЛЬКО ДЛ МЕТЧИКОВ) ERT ЦАНГОВЫЕ ПАТРОНЫ ER ER SPANNUNG FRÄSERSPANNFUTTER - ER - FÜR GEWINDESCHNEID FRÄSERSPANNFUTTER - ER - FÜR CNC DREHBANK TENSION MANDRIN À PINCES - ER - POUR TARAUDER MANDRIN À PINCES - ER - POUR CNC TOUR TENSIONAMENTO MANDRINO PORTA PINZE - ER - PER MASCHIARE MANDRINO PORTA PINZE - ER - PER CNC TORNIO TENSIÓN PORTAPINZAS - ER - PARA HILO PORTAPINZAS - ER - PARA CNC TORNO H H L L L1 ■ STRAIGHT-K ■ NC- for CNC LATHE Unit : mm ◆ STANDARD Unit : mm TAPER No. MODEL No. EDP No. CLAMPING RANGE D1 D2 L H NUT / COLLET WEIGHT (Kg) TAPER No. MODEL No. EDP No. CLAMPING RANGE D D1 L L1 H NUT / COLLET WEIGHT (Kg) 20 K20-ERT16-70 P2772212 0.5 - 10.0 20 28 70 31.7 ER16 0.40 NC25-ER11 P2772310 0.5 - 7.0 25 19 65 32 28.6 ER11 0.30 K25-ERT16-80 P2772213 0.5 - 10.0 25 28 80 31.7 ER16 0.4525 NC25-ER16 P2772311 0.5 - 10.0 25 28 65 35.9 - ER16 0.4525 K25-ERT20-80 P2772214 0.5 - 13.0 25 34 80 35.5 ER20 0.50 NC25-ER20 P2772301 0.5 - 13.0 25 34 65 40 44.5 ER20 0.50 K32-ERT16-80 P2772215 0.5 - 10.0 32 28 80 31.7 ER16 0.70 NC25-ER25 P2772302 1.0 - 16.0 25 42 65 41 41 ER25 0.55 K32-ERT20-80 P2772216 0.5 - 13.0 32 34 80 35.5 ER20 0.80 NC32-ER20 P2772303 0.5 - 13.0 32 34 60 39.5 44.5 ER20 0.60 32 K32-ERT25-80 P2772217 1.0 - 16.0 32 42 80 42 ER25 1.00 32 NC32-ER25 P2772304 1.0 - 16.0 32 42 70 40 41 ER25 0.70 K32-ERT32-80 P2772218 1.0 - 20.0 32 50 80 48 ER32 1.20 NC32-ER32 P2772305 1.0 - 20.0 32 50 70 45 47 ER32 0.75 NC40-ER32 P2772306 1.0 - 20.0 40 50 75 45 60 ER32 1.25 40 NC40-ER40 P2772307 2.0 - 30.0 40 63 75 55 53 ER40 1.30 ◆ EXTENDED Unit : mm TAPER No. MODEL No. EDP No. CLAMPING RANGE D D1 L L1 H NUT / COLLET WEIGHT (Kg) NC25-ER11G P2772310G 0.5 - 7.0 25 19 65 32 28.6 ER11 0.30 NC25-ER16G P2772311G 0.5 - 10.0 25 28 65 35.9 - ER16 0.45 25 NC25-ER20G P2772301G 0.5 - 13.0 25 34 65 40 44.5 ER20 0.50 NC25-ER25G P2772302G 1.0 - 16.0 25 42 65 41 41 ER25 0.55 NC32-ER20G P2772303G 0.5 - 13.0 32 34 60 39.5 44.5 ER20 0.60 32 NC32-ER25G P2772304G 1.0 - 16.0 32 42 70 40 41 ER25 0.70 NC32-ER32G P2772305G 1.0 - 20.0 32 50 70 45 47 ER32 0.75 NC40-ER32G P2772306G 1.0 - 20.0 40 50 75 45 60 ER32 1.25 40 NC40-ER40G P2772307G 2.0 - 30.0 40 63 75 55 53 ER40 1.30 H G L L1 ■ BRIDGEPORT-R8 Unit : mm TAPER No. MODEL No. EDP No. CLAMPING RANGE G D1 L L1 H NUT / COLLET WEIGHT (Kg) R8-ER32 P2772308 1.0 - 20.0 U7/16 50 102.4 50 40 ER32 1.00 R8 R8-ER40 P2772309 2.0 - 30.0 U7/16 63 102.4 75 51 ER40 1.20 090 Phone: +82-32-526-0909, www.yg1.kr, E-mail: yg1@yg1.kr Phone: +82-32-526-0909, www.yg1.kr, E-mail: yg1@yg1.kr 091
