D D HydraulicShrink FitER ColletEnd Mill HolderShell MillPower MillingMorse TaperSK SlimSynchroTappingTappingFace MillNC Drill ChuckBoringAccessory ChuckHolderChuck& Side Lock ArborArborChuckArborChuckTapping ChuckER ChuckChuckArbor& Other Tool HoldersSystem& Others & OthersSystem& Other Tool HoldersArborChuckER ChuckTapping ChuckChuckArborChuckArbor& Side Lock ArborChuckHolderChuck AccessoryBoringNC Drill ChuckFace MillTappingTappingSynchroSK SlimMorse TaperPower MillingShell MillEnd Mill HolderER ColletShrink FitHydraulic ER COLLET CHUCK ER COLLET CHUCK ER COLLET CHUCK ER ER COLLET CHUCK ER FRÄSERSPANNFUTTER - ER FRÄSERSPANNFUTTER - ER MANDRIN À PINCES - ER MANDRIN À PINCES - ER MANDRINO PORTA PINZE - ER MANDRINO PORTA PINZE - ER PORTAPINZAS - ER PORTAPINZAS - ER B H H AD TAPER No. L NUT TAPER No. B L NUT CBT TaperAccuracyG Value RPM CoolantSystem■ CBT (BT DUAL CONTACT)AT32.525,000AD■ JIS B6339/MAS 403-BT TaperJIS B6339AccuracyG ValueRPM CoolantSystem- BTAT32.525,000AD or AD/B Unit : mm Unit : mm TAPER No. MODEL No. EDP No. CLAMPING RANGE L D H NUT / COLLET WEIGHT (Kg) TAPER No. MODEL No. EDP No. CLAMPING RANGE L D H NUT / COLLET WEIGHT (Kg) CBT50-ER16-100 P2772018 0.5 - 10.0 100 28 45 ER16 4.20 BT30-ER11-70 P2776501A 0.5 - 7.0 70 19 45 ER11 0.50 CBT50-ER16-120 P2772019 0.5 - 10.0 120 28 45 ER16 4.40 BT30-ER11-100 P2776502A 0.5 - 7.0 100 19 45 ER11 0.50 CBT50-ER16-165 P2772020 0.5 - 10.0 165 28 45 ER16 4.60 BT30-ER16-70 P2776503A 0.5 - 10.0 70 28 45 ER16 1.00 CBT50-ER20-100 P2772021 0.5 - 13.0 100 34 50 ER20 4.60 BT30-ER16-100 P2776506A 0.5 - 10.0 100 28 45 ER16 1.10 CBT50-ER20-135 P2772022 0.5 - 13.0 135 34 50 ER20 4.80 BT30-ER20-80 P2776507A 0.5 - 13.0 80 34 50 ER20 1.20 30 CBT50-ER20-165 P2772023 0.5 - 13.0 165 34 50 ER20 5.00 BT30-ER20-100 P2776508A 0.5 - 13.0 100 34 50 ER20 1.30 CBT50-ER25-100 P2772024 1.0 - 16.0 100 42 65 ER25 4.70 BT30-ER25-70 P2776509A 1.0 - 16.0 70 42 65 ER25 1.20 CBT50-ER25-135 P2772025 1.0 - 16.0 135 42 65 ER25 4.80 BT30-ER25-100 P2776510A 1.0 - 16.0 100 42 65 ER25 1.30 50 CBT50-ER25-165 P2772026 1.0 - 16.0 165 42 65 ER25 5.00 BT30-ER32-60 P2776511A 1.0 - 20.0 60 50 65 ER32 1.40 CBT50-ER32-100 P2772027 1.0 - 20.0 100 50 65 ER32 5.20 BT30-ER32-90 P2776512A 1.0 - 20.0 90 50 65 ER32 1.90 CBT50-ER32-135 P2772028 1.0 - 20.0 135 50 65 ER32 5.70 BT40AD/B-ER11-75 P2776513 0.5 - 7.0 75 19 45 ER11 1.00 CBT50-ER32-165 P2772029 1.0 - 20.0 165 50 65 ER32 5.80 BT40AD/B-ER11-100 P2776514 0.5 - 7.0 100 19 45 ER11 1.10 CBT50-ER40-100 P2772030 2.0 - 30.0 100 63 75 ER40 5.60 BT40AD/B-ER16-75 P2776504 0.5 - 10.0 75 28 45 ER16 1.10 CBT50-ER40-150 P2772031 2.0 - 30.0 150 63 75 ER40 6.10 BT40AD/B-ER16-100 P2553021 0.5 - 10.0 100 28 45 ER16 1.20 CBT50-ER50-100 P2772032 4.0 - 34.0 100 78 85 ER50 5.80 BT40AD/B-ER16-120 P2776515 0.5 - 10.0 120 28 45 ER16 1.40 CBT50-ER50-150 P2772033 4.0 - 34.0 150 78 85 ER50 6.30 BT40AD/B-ER20-75 P2776516 0.5 - 13.0 75 34 50 ER20 1.40 ▶ For applicable ER collet, please refer to page 95~99. BT40AD/B-ER20-100 P2553017 0.5 - 13.0 100 34 50 ER20 1.8040 ▶ For applicable ER nut, Sealing disk and Spanner, please refer to page 100~104. BT40AD/B-ER20-135 P2776517 0.5 - 13.0 135 34 50 ER20 2.20 BT40AD/B-ER25-75 P2600012 1.0 - 16.0 75 42 65 ER25 1.40 BT40AD/B-ER25-100 P2553018 1.0 - 16.0 100 42 65 ER25 1.80 BT40AD/B-ER25-135 P2776518 1.0 - 16.0 135 42 65 ER25 2.20 BT40AD/B-ER25-150 P2776519 1.0 - 16.0 150 42 65 ER25 2.40 BT40AD/B-ER32-60 P2553501 1.0 - 20.0 60 50 65 ER32 1.80 BT40AD/B-ER32-100 P2776505 1.0 - 20.0 100 50 65 ER32 2.20 ▶ CAT(ANSI B5.50) taper and Inch type products are available. ▶ For applicable ER collet, please refer to page 95~99. ▶ For applicable ER nut, Sealing disk and Spanner, please refer to page 100~104. 078 Phone: +82-32-526-0909, www.yg1.kr, E-mail: yg1@yg1.kr Phone: +82-32-526-0909, www.yg1.kr, E-mail: yg1@yg1.kr 079
