Special Threads, Gauges Intro M-MF Code LF (mm) L D1 D2 DCON L1(mm)(Thread engagement ratio) (Thread engagement ratio)(mm)(mm)L2(mm)L3(mm)TypeStock YMW CPCS8.0MA 99 22 6.917 (100%) 7.026 (90%) 8 12 16 20 01 f SP CPCS8.0MB 99 22 6.972 (95%) 7.080 (85%) 8 12 16 20 01 f CPCS8.0MC 99 22 7.026 (90%) 7.134 (80%) 8 12 16 20 01 f CPCS8.0MD 99 22 7.080 (85%) 7.188 (75%) 8 12 16 20 01 f M8X1 CPCS8.0ME 99 22 7.134 (80%) 7.242 (70%) 8 12 16 20 01 f SL CPCS8.0MF 99 22 7.188 (75%) 7.296 (65%) 8 12 16 20 01 f CPCS8.0MM set of 5pcs. CPCS8.0MB (95%) ~ CPCS8.0MF (65%) 01 f CPCS8.0MS set of 5pcs. CPCS8.0MA (100%) ~ CPCS8.0ME (70%) 01 f PO CPCS8.0JA 99 22 7.188 (100%) 7.269 (90%) 8 12 16 20 01 f CPCS8.0JB 99 22 7.229 (95%) 7.310 (85%) 8 12 16 20 01 f CPCS8.0JC 99 22 7.269 (90%) 7.350 (80%) 8 12 16 20 01 f CPCS8.0JD 99 22 7.310 (85%) 7.391 (75%) 8 12 16 20 01 f ST M8X0.75 CPCS8.0JE 99 22 7.350 (80%) 7.432 (70%) 8 12 16 20 01 f CPCS8.0JF 99 22 7.391 (75%) 7.472 (65%) 8 12 16 20 01 f CPCS8.0JM set of 5pcs. CPCS8.0JB (95%) ~ CPCS8.0JF (65%) 01 f CPCS8.0JS set of 5pcs. CPCS8.0JA (100%) ~ CPCS8.0JE (70%) 01 f ROLL CPCS9.0NA 110 27.5 7.647 (100%) 7.782 (90%) 10 13.5 18 22.5 01 f CPCS9.0NB 110 27.5 7.714 (95%) 7.850 (85%) 10 13.5 18 22.5 01 f CPCS9.0NC 110 27.5 7.782 (90%) 7.917 (80%) 10 13.5 18 22.5 01 f CARBIDE M9X1.25 CPCS9.0ND 110 27.5 7.850 (85%) 7.985 (75%) 10 13.5 18 22.5 01 f CPCS9.0NE 110 27.5 7.917 (80%) 8.053 (70%) 10 13.5 18 22.5 01 f CPCS9.0NF 110 27.5 7.985 (75%) 8.120 (65%) 10 13.5 18 22.5 01 f CPCS9.0NM set of 5pcs. CPCS9.0NB (95%) ~ CPCS9.0NF (65%) 01 f LONG CPCS9.0NS set of 5pcs. CPCS9.0NA (100%) ~ CPCS9.0NE (70%) 01 f CPCS9.0MA 110 27.5 7.917 (100%) 8.026 (90%) 10 13.5 18 22.5 01 f CPCS9.0MB 110 27.5 7.972 (95%) 8.080 (85%) 10 13.5 18 22.5 01 f HAND CPCS9.0MC 110 27.5 8.026 (90%) 8.134 (80%) 10 13.5 18 22.5 01 f TAPS CPCS9.0MD 110 27.5 8.080 (85%) 8.188 (75%) 10 13.5 18 22.5 01 f M9X1 CPCS9.0ME 110 27.5 8.134 (80%) 8.242 (70%) 10 13.5 18 22.5 01 f CPCS9.0MF 110 27.5 8.188 (75%) 8.296 (65%) 10 13.5 18 22.5 01 f EG (STI) CPCS9.0MM set of 5pcs. CPCS9.0MB (95%) ~ CPCS9.0MF (65%) 01 f CPCS9.0MS set of 5pcs. CPCS9.0MA (100%) ~ CPCS9.0ME (70%) 01 f CPCS9.0JA 110 27.5 8.188 (100%) 8.269 (90%) 10 13.5 18 22.5 01 f SPECIAL CPCS9.0JB 110 27.5 8.229 (95%) 8.310 (85%) 10 13.5 18 22.5 01 f THREADS,GAUGES CPCS9.0JC 110 27.5 8.269 (90%) 8.350 (80%) 10 13.5 18 22.5 01 f YMW M9X0.75 CPCS9.0JD 110 27.5 8.310 (85%) 8.391 (75%) 10 13.5 18 22.5 01 f CPCS9.0JE 110 27.5 8.350 (80%) 8.432 (70%) 10 13.5 18 22.5 01 f THREAD CPCS9.0JF 110 27.5 8.391 (75%) 8.472 (65%) 10 13.5 18 22.5 01 f MILLS CPCS9.0JM set of 5pcs. CPCS9.0JB (95%) ~ CPCS9.0JF (65%) 01 f CPCS9.0JS set of 5pcs. CPCS9.0JA (100%) ~ CPCS9.0JE (70%) 01 f CPCS010OA 110 27.5 8.376 (100%) 8.538 (90%) 10 15 20 25 01 f DIES CPCS010OB 110 27.5 8.457 (95%) 8.620 (85%) 10 15 20 25 01 f CPCS010OC 110 27.5 8.538 (90%) 8.701 (80%) 10 15 20 25 01 f CPCS010OD 110 27.5 8.620 (85%) 8.782 (75%) 10 15 20 25 01 f CENTER M10X1.5 CPCS010OE 110 27.5 8.701 (80%) 8.863 (70%) 10 15 20 25 01 f DRILLS CPCS010OF 110 27.5 8.782 (75%) 8.944 (65%) 10 15 20 25 01 f CPCS010OM set of 5pcs. CPCS010OB (95%) ~ CPCS010OF (65%) 01 f CPCS010OS set of 5pcs. CPCS010OA (100%) ~ CPCS010OE (70%) 01 f Technical info 564
