Grooving and Cut-Off ProGroove™ Grooving and Profiling Integral Holders Right Hand Tool Shown „Grooving and Profiling seat cap cap order number catalogue number size W CD D max H B F L1 L2 H1 screw screw wrench right hand 2007105 12251762000 2 2,10 10,0 25,4 16 16,0 16,2 100 26 16 — 12146012600 12148041100 2021637 12251762400 2 2,10 10,0 25,4 25 25,0 25,2 150 26 25 — 12146012600 12148041100 2007111 12251763200 2 3,10 10,0 25,4 25 25,0 25,3 150 26 20 12148596200 — — 2007127 12251763400 3 3,10 10,0 25,4 16 16,0 16,3 100 26 25 12148596200 — — 2007130 12251764200 3 4,10 12,5 32,0 25 25,0 25,4 150 31 25 12148596200 — — 2007832 12251762200 4 2,10 10,0 25,4 20 20,0 20,2 125 26 25 — 12146012600 12148041100 2022548 12251764000 4 4,10 12,5 32,0 20 20,0 20,4 125 31 20 12148596200 — — 2022550 12251764400 4 4,10 12,5 32,0 32 25,0 25,4 170 31 32 12148596200 — — 2022552 12251765200 5 5,10 12,5 — 25 25,0 25,5 150 31 25 12148596200 — — 2015792 12251768400 5 8,10 16,0 — 32 25,0 25,7 170 36 32 — 12146012700 12148041300 2022555 12251766200 6 6,10 16,0 — 25 25,0 25,6 150 35 25 — 12146012700 12148041300 2022557 12251766400 6 6,10 16,0 — 32 25,0 25,6 170 35 32 — 12146012700 12148041300 2015754 12251763000 8 3,10 10,0 25,4 20 20,0 20,3 125 26 25 12148596200 — — left hand 2007108 12251762100 2 2,10 10,0 25,4 16 16,0 16,2 100 26 16 — 12146012600 12148041100 2021636 12251762500 2 2,10 10,0 25,4 25 25,0 25,2 150 26 25 — 12146012600 12148041100 2007124 12251763300 2 3,10 10,0 25,4 25 25,0 25,3 150 26 20 12148596200 — — 2021631 12251762300 3 2,10 10,0 25,4 20 20,0 20,2 125 26 16 — 12146012600 12148041100 2022547 12251763100 3 3,10 10,0 25,4 20 20,0 20,3 125 26 20 12148596200 — — 2007133 12251764300 3 4,10 12,5 32,0 25 25,0 25,4 150 31 25 12148596200 — — 2015782 12251765500 3 5,10 12,5 — 32 25,0 25,5 170 31 20 12148596200 — — 2022549 12251764100 4 4,10 12,5 32,0 20 20,0 20,4 125 31 20 12148596200 — — 2022551 12251764500 4 4,10 12,5 32,0 32 25,0 25,4 170 31 32 12148596200 — — 2022553 12251765300 5 5,10 12,5 — 25 25,0 25,5 150 31 25 12148596200 — — 2022556 12251766300 6 6,10 16,0 — 25 25,0 25,6 150 35 25 — 12146012700 12148041300 2022558 12251766500 6 6,10 16,0 — 32 25,0 25,6 170 35 32 — 12146012700 12148041300 2021627 12251763500 8 3,10 10,0 25,4 16 16,0 16,3 100 26 32 12148596200 — — 2022559 12251768500 8 8,10 16,0 — 32 25,0 25,7 170 36 32 — 12146012700 12148041300 NOTE: Select shorter CD dimension for added stability. widia.com E103
