Grooving and Cut-Off WP10CT––––––WP10CT––– WP25CT––––––WP25CT––– WU10PT––––––WU10PT––– WU25PT416966941696744169577416968341696634169693WU25PT416968141696914169687 WU10HT––––––WU10HT––– WMT™ Turning, Grooving, and Cut-Off Cut-Off Inserts with Wiper P ⅷ ⅷ ࠗ ࠗ M ⅷ ⅷ ࠗ ⅷ first choice K ⅷ ⅷ ࠗ ࠗ ࠗ alternate choice Neutral Left Hand N ⅷ ⅷ ⅷ RR = RL on neutral inserts S ⅷ ⅷ ⅷ H ࠗ WMT-CM-W seat catalogue number size W RR LI hand WMTC015N00CMW08 1 1,50 0,08 19,30 N - Neutral WMTC020N00CMW08 2 2,00 0,08 19,21 N - Neutral WMTC094N00CMW13 2B 2,39 0,13 22,32 N - Neutral WMTC030N00CMW17 3 3,00 0,17 25,40 N - Neutral WMTC125N00CMW17 3 3,18 0,17 25,41 N - Neutral WMTC040N00CMW17 4 4,00 0,17 25,40 N - Neutral seat catalogue number size W RR LI _L hand WMTC020L12CMW08 2 2,00 0,08 19,27 12 L - Left WMTC030L12CMW17 3 3,00 0,17 25,40 12 L - Left WMTC030L05CMW17 3 3,00 0,17 25,40 5 L - Left (continued) E16 widia.com
