CW CDX aa WF DCONMSh6DCONMSh6 Turning TBGR Solid boring bar for internal grooving DMIN LF LH CW Details of edge Designation SH725 CW+0.05 0 DMIN DCONMS WF a LF LH CDX TBGR04100050-D020  0.5 2 4 -0.2 1.8 26 10 0.4 TBGR04090100-D040  1 4 4 1.5 3.5 25.5 9 0.8 TBGR04150100-D040  1 4 4 1.5 3.5 31.5 15 0.8 TBGR07090200-D050  2 5 7 0.9 4.4 25 9 1 TBGR07090100-D060  1 6 7 1.8 5.3 25 9 1.8 TBGR07140100-D060  1 6 7 1.8 5.3 30 14 1.8 TBGR07090150-D060  1.5 6 7 1.8 5.3 25 9 1.8 TBGR07090200-D060  2 6 7 1.8 5.3 25 9 1.8 TBGR07140200-D060  2 6 7 1.8 5.3 30 14 1.8 TBGR07090100-D068  1 6.8 7 2.7 6.2 25 9 2.5 TBGR07090150-D068  1.5 6.8 7 2.7 6.2 25 9 2.5 TBGR07140150-D068  1.5 6.8 7 2.7 6.2 30 14 2.5 TBGR07090200-D068  2 6.8 7 2.7 6.2 25 9 2.5 TBGR07140200-D068  2 6.8 7 2.7 6.2 30 14 2.5 TBGR07210200-D068  2 6.8 7 2.7 6.2 37 21 2.5 TBGR07290200-D068  2 6.8 7 2.7 6.2 45 29 2.5 * Corner radius : less than 0.1 mm.  : Will be released in December 2021 TBFR Solid boring bar for face grooving DMIN LF CDX LH Details of edge Designation SH725 CW+0.05 0 DMIN DCONMS a LF LH CDX TBFR07110100-D060  1 6 7 5.2 26 10 1.5 TBFR07110200-D060  2 6 7 5.2 26 10 3 TBFR07110100-D080  1 8 7 5.9 27 11 1.5 TBFR07110250-D080  2.5 8 7 5.9 27 11 3.5 TBFR07300300-D080  3 8 7 5.9 46 30 3.5 TBFR07200250-D150  2.5 15 7 5.9 36 20 20 TBFR07200300-D150  3 15 7 5.9 36 20 20 TBFR07300300-D150  3 15 7 5.9 46 30 30 * Corner radius : less than 0.1 mm.  : Will be released in December 2021 Tungaloy 57
