Mini Carbide Boring Tools A\ Internal Grooving (Round) Boring and Profiling D min. D . min „ t max. loolholder face Klemmhalter Stimseite toolholder face Designation(Internal) b S f a d tmax Dmin R Designation(Internal) d S a f tmax Dmin R MB 09GR/ L - B150- 5.5D16- R0.75 1.50 4.7 10.5 15.0 9 5.5 16.0 0.75 MB 04PR/L-D06-R0.20 4 2.6 5.0 3.0 0.8 5.5 0.2 09GR/ L - B200- 5.5D16- R1.00 2.00 4.7 10.5 15.0 9 5.5 16.0 1.00 05PR/L-D07-R0.20 5 3.3 6.1 3.6 1.0 6.5 0.2 09GR/ L - B300- 5.5D16- R1.50 3.00 4.7 10.5 15.0 9 5.5 16.0 1.50 07PR/L-D10-R0.20 7 3.5 9.5 6.0 2.0 10.0 0.2 09GR/L-B150-6.5D17-R0.75 1.50 4.7 11.5 16.0 9 6.5 17.0 0.75 09PR/L-D14-R0.20 9 4.7 13.2 8.7 4.0 13.8 0.2 09GR/ L - B200- 6.5D17 - R1.00 2.00 4.7 11.5 16.0 9 6.5 17.0 1.00 09GR/L-B300-6.5D17-R1.50 3.00 4.7 11.5 16.0 9 6.5 17.0 1.50 11GR/L-B150-4.3D16-R0.75 1.50 5.3 10.2 15.7 11 4.3 16.0 0.75 11GR/L-B200-4.3D16-R1.00 2.00 5.3 10.2 15.7 11 4.3 16.0 1.00 Copying 11GR/L-B250-4.3D16-R1.25 2.50 5.3 10.2 15.7 11 4.3 16.0 1.25 11GR/L-B300-4.3D16-R1.50 3.00 5.3 10.2 15.7 11 4.3 16.0 1.50 11GR/L-B400-4.3D16-R2.00 4.00 5.3 10.2 15.7 11 4.3 16.0 2.00 11GR/L-B150-6.0D18-R0.75 1.50 5.3 12.0 17.5 11 6.0 18.0 0.75 11GR/ L - B200- 6.0D18 - R1.00 2.00 5.3 12.0 17.5 11 6.0 18.0 1.00 D -. min ^ ^X 11GR/L-B250-6.0D18-R1.25 2.50 5.3 12.0 17.5 11 6.0 18.0 1.25 11GR/ L - B300- 6.0D18 - R1.50 3.00 5.3 12.0 17.5 11 6.0 18.0 1.50 11GR/L-B400-6.0D18-R2.00 4.00 5.3 12.0 17.5 11 6.0 18.0 2.00 11GR/L-B150-8.0D20-R0.75 1.50 5.3 14.0 19.5 11 8.0 20.0 0.75 Klemmhalter Stimseitetoolholderface 11GR/L-B200-8.0D20-R1.00 2.00 5.3 14.0 19.5 11 8.0 20.0 1.00 11GR/L-B250-8.0D20-R1.25 2.50 5.3 14.0 19.5 11 8.0 20.0 1.25 11GR/L-B300-8.0D20-R1.50 3.00 5.3 14.0 19.5 11 8.0 20.0 1.50 11GR/L - B400- 8.0D20- R2.00 4.00 5.3 14.0 19.5 11 8.0 20.0 2.00 Designation(Internal) d S a f tmax Dmin R MB 04QR-1.4D06-R0.20 4 2.6 5.7 3.7 1.4 6.0 0.2 05QR/L-1.5D07-R0.20 5 3.3 6.8 4.3 1.5 7.0 0.2 05QR/L-3.5D09-R0.20 5 3.3 8.5 5.5 3.5 9.0 0.2 07QR/L-2.0D10-R0.20 7 3.5 9.5 6.0 2.0 10.0 0.2 07QR/L-3.5D12-R0.20 7 3.5 11.0 7.5 3.5 12.0 0.2 09QR/L-4.0D14-R0.20 9 4.7 13.5 9.0 4.0 14.0 0.2 09QR/L-6.0D16-R0.20 9 4.7 15.5 11.0 6.0 16.0 0.2 09QR/L-7.0D17-R0.20 9 4.7 16.5 12.0 7.0 17.0 0.2 11QR/L-4.0D16-R0.20 11 5.3 15.5 10.0 4.0 16.0 0.2 11QR/L-8.0D20-R0.20 11 5.3 19.5 14.0 8.0 20.0 0.2 063 064
